Denon AVR-1713 Service Manual

150
PARTS LIST OF P.C.B. UNIT
z
Parts indicated by "nsp" on this table cannot be supplied.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe modelE1C : China model
E1C : China model
FRONT PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 943239005300M I.C,OPAMP
HVIBA4560RF
Q1001 943219006820S TR KTC1027Y CVTKTC1027YT
Q1002 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q1003 943214500020S T.R,2SC3052 CVT2SC3052
Q1004 943214500020S T.R,2SC3052 CVT2SC3052
Q1005 00MHT600141B1 TR KTA1271Y HVTKTA1271YT
Q1006 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q1007 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q1008 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q1009 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q1011 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q1012 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
D1001 00D9630328409 DIODE,RECTIFIERS CVD1N4007ST
D1002 00D9630328409 DIODE,RECTIFIERS CVD1N4007ST
D1003 90M-HD302360R DIODE,ZENER,1/2W,6.8V CVDZJ6.8BT
D1004 00D9430087209 DIODE,ZENER,1/2W,24V CVDZJ24BT
D1005 90M-HD302450R DIODE,ZENER,1/2W,13V CVDZJ13BT
D1008 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1
D1009 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1
D1010 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1
D1011 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1
D1012 943176010090S L.E.D,(GREEN/RED5PI) CVDBLBJEGJ204L
D1019 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
D1020 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
D1401 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT
D1402 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT
D1403 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT
D1404 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
D1405 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
RESISTORS GROUP
R1001 nsp RES,CARBON(1/5W,1.8ohm,J)
CRD20TJ1R8T
R1004 nsp RES,CARBON(1/5W,1.8ohm,J) CRD20TJ1R8T
R1005 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R1006 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R1007 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
R1008 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R1009 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R1010 00MNN05393610 RES,CHIP(1608/5%/39Kohm) CRJ10DJ393T
R1011 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R1012 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1013 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1014 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1015 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1016 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R1017 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R1018 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1019 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1020 00MNN05332610 RES,CHIP(1608/5%/3.3Kohm) CRJ10DJ332T
R1021 00MNN05102610 RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T
R1022 00MNN05102610 RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T
R1023 00MNN05473610 RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
