Denon AVR-1713 Service Manual

157
MAIN PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q5101 943211500150S
PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5102 943211500150S
PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5103 943213500150S
NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA *
Q5104 90M-HT800120R
T.R,BIAS HVTKTC3114A
Q5105 90M-HT400490R T.R,POWER HVT2SD2390
Q5106 90M-HT200440R T.R,POWER HVT2SB1560
Q5107 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5108 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5201 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5202 943211500150S
PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5203 943213500150S
NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA *
Q5204 90M-HT800120R
T.R,BIAS HVTKTC3114A
Q5205 90M-HT400490R T.R,POWER HVT2SD2390
Q5206 90M-HT200440R T.R,POWER HVT2SB1560
Q5207 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5208 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5301 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5302 943211500150S
PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5303 943213500150S
NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA *
Q5304 90M-HT800120R
T.R,BIAS HVTKTC3114A
Q5305 90M-HT400490R T.R,POWER HVT2SD2390
Q5306 90M-HT200440R T.R,POWER HVT2SB1560
Q5307 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5308 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5401 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5402 943211500150S
PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5403 943213500150S
NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA *
Q5404 90M-HT800120R
T.R,BIAS HVTKTC3114A
Q5405 90M-HT400490R T.R,POWER HVT2SD2390
Q5406 90M-HT200440R T.R,POWER HVT2SB1560
Q5407 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5408 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5501 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5502 943211500150S
PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5503 943213500150S
NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA *
Q5504 90M-HT800120R
T.R,BIAS HVTKTC3114A
Q5505 90M-HT400490R T.R,POWER HVT2SD2390
Q5506 90M-HT200440R T.R,POWER HVT2SB1560
Q5507 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5508 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5601 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C *
Q5602 943213500160S
T.R,RT1N237C(2.2K-47K) CVTRT1N237C *
Q5603 943213500160S
T.R,RT1N237C(2.2K-47K) CVTRT1N237C *
Q5604 943213500160S
T.R,RT1N237C(2.2K-47K) CVTRT1N237C *
Q5701 943212500020S
HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5702 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5703 943214500040S
HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5704 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5705 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5706 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5707 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5708 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
D5102 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5103 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5104 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5105 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5106 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5202 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5203 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5204 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5205 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5206 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5302 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
