Denon AVR-1713 Service Manual

18
1. µcom/DSP Version display mode
1.1. Operationspecications
µcom/DSP version display mode:
When the set is started up in this mode, the version information is displayed.
Starting up:
Press the
X
button to turn on the power while pressing the "STATUS" and "DIMMER" buttons.
Now, press the "STATUS" button to the display the 2nd item information on the FL Display.
b
When the version is displayed on the FL Display, the version list is also displayed on the GUI.
1.2. Display Order
Error information(Refer to 1.3. Error display) →
q
Model destination information →
w
Firmware Package Version
→
e
Main µ-com →
r
Main 1st Boot Loader →
t
DSP ROM →
y
Audio PLD →
u
GUI SFLASH
→ *
i
Ethernet(DM860) 1st Boot Loader, Hardware ID → *
o
Ethernet(DM860) 2nd Boot Loader, Rhapsody Flag
→ *
Q0
Ethernet(DM860) IMAGE → *
Q1
Ethernet(DM860)MAC ADDRESS information
q
Model destination information :
Model FLD
AVR-1613 E3 model
A V R 1 6 1 3 E 3
AVR-1713 E3 model
A V R 1 7 1 3 E 3
AVR-1713 E2 model
A V R 1 7 1 3 E 2
AVR-1713 E1C model
A V R 1 7 1 3 E 1 C
AVR-1723 E1C model
A V R 1 7 2 3 E 1 C
w
Firmware Package Version :
FLD
P a c k a g e : * * * *
e
Main µ-com :
FLD
M a i n : * * * * # # # #
(*: Main version, #: Sub version)
r
Main 1st Boot Loader :
FLD
M a i n F B L : * * . * *
t
DSP ROM :
FLD
D S P : * * . * *
y
Audio PLD :
FLD
A u d i o P L D : * * . * *
u
GUI SFLASH :
Model FLD
AVR-1613 E3 model
G U I : 5 7 1 8 * * * *
AVR-1713 E3 model
G U I : 5 7 1 1 * * * *
AVR-1713 E2 model
G U I : 5 7 1 2 * * * *
AVR-1713 E1C model
G U I : 5 7 1 5 * * * *
AVR-1723 E1C model
G U I : 5 7 1 6 * * * *
