56
1
Set up the
remote control unit
n Set up the zone mode
Press ZONE SELECT to switch the zone mode to
J (MAIN ZONE).
The J indicator lights.
Press ZONE SELECT
n Set up the operation mode
Press AMP to set the remote control unit to AMP-
operation mode.
Press AMP
2
Connect the setup microphone.
MultEQ
Preparation
Connect the speakers and place then according
to the recommendations in the manual.
Next
Audyssey Auto Setup
[RETURN][ENTER] Enter Cancel
When the setup microphone is
connected, the following screen is
displayed.
3
Select “Next”, and then press
ENTER.
Set up speakers
around items indicate the settings.
Here we describe how to set up speakers other than 5.1-channel speakers.
For the method of setting up 5.1-channel speakers, see C page 4 “Setup wizard”.
First install and connect the speakers to this unit.
Before Auto Setup measurement, the settings shown below can be made.
•Changing the amplifier assignment (Amp Assign)
The signal output from the SURR.BACK/AMP ASSIGN speaker terminal of this unit can be switched to match your speaker environment (vpage56 “Set up “Amp Assign””).
•Setting the channels to be used (Channel Select)
If channels that are not to be used are set in advance, measurement for the set channels is skipped, and measuring time can be reduced. You can also change the number of surround back speakers (vpage57
“Set up “Channel Select””).
4
Set up “Amp Assign”
Use ui to select “Amp Assign”, and then press
ENTER.
MultEQ
Amp Assign ZONE2
ZONE2
Amp Assign
[RETURN][ENTER] Enter Cancel
MultEQ
Preparation
Set the following items
if necessary.
Amp Assign
Channel Select
Audyssey Auto Setup
Auto Setup Start
[RETURN][ENTER] Enter Cancel
To Next Page
