Denon AVR-1912 User Manual

66
Web control function
You can operate this unit using a browser.
1
Switch the “Network Standby” setting to “ON”.
(vpage 90).
2
Check the IP address of this unit with “Network
Info.” (vpage 91).
Network Info.
Friendly Name
DHCP
IP Address
MAC Address
DENON:[AVR-1912]
ON
192.168.100.19
0005cd-004210
[ ] Return
Checking the IP address.
3
Enter the IP address of this unit in browser’s address
box.
For example, if the IP address of this unit is “192.168.100.19”,
enter “http://192.168.100.19/”.
http://192.168.100.19/index.asp
INDEX
File
Edit View Tools HelpFavorites
MAIN ZONE
-20.0dB
Status
ZONE2
-40dB
Status
Web Controller
DENON:[AVR-1912]
Web Controller Config.
q
q Entering the IP address.
4
When the top menu is displayed, click on the menu
item you want to operate.
http://192.168.100.19/index.asp
INDEX
File
Edit View Tools HelpFavorites
MAIN ZONE
-20.0dB
Status
ZONE2
-40dB
Status
Web Controller
DENON:[AVR-1912]
Web Controller Config.
w
e
w Click when you operate each zone. (vGExample 1H)
e Click to change the Web control screen setting.
(vGExample 2H)
5
Operate.
GExample 1H Main zone control screen
MAIN ZONE
POWER
NET/USB
SOURCE
MAIN ZONE Sleep Timer
MOVIE
Player
Video
Network
Tuner
-20.0dB
SORROUND STEREO
Note
To use the web control function,set the GUI menu System Setup” - “Network Setup” - “Other” -“Network Standby” setting to “ON”
∞ -80 18100-10-20-30-40-50-60-70
QUICK SELECT
>
><
ON STANDBY
MUSIC GAME
ON OFF
CHANNEL LEVEL
>
ZONE CONTROL
>
NETAUDIO/USB
>
iPod Dock
>
iPod Direct
>
RELOAD
Add To Your Favorite
Top Menu
r
t
y
Q1
i
Q0
o
u
r Click to perform individual operations.
Changes to individual operation screens. (vGExample 3H)
t Click when you update to the latest information.
Normally, there is a change to the latest information each time
you operate. When operating from the main unit, click this or else
the screen will not be updated.
y Click to add a setting to “Favorites” in your browser.
We recommend registering the setting screens for the different
zones in the browser’s favorites so as not to accidentally perform
menu operations for zones you do not intend to operate.
u Click to return to the top menu.
Displayed when setting “Top Menu Link Setup” to “ON” in
GExample 2H
i Click when you perform a power operation of the unit.
o Click an icon to change the input source.
Q0 Click “v” and then select a surround mode from the displayed
items.
Q1 To adjust the main volume, click “<”, “>” or the volume display.
Convenient functions
Basic version
Advanced version
Information
Advanced version
vSee overleaf
BD

Denon AVR-1912 Specifications

General

Impedance	47 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
Ethernet LAN	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL
Display	-
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	167 mm
Weight	10200 g
