Denon AVR-2106 Service Manual

48
AVR-2106/886
CNT P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC551 00D 963 0218 807 IC BU4094BCF
IC552 00D 963 0218 807 IC BU4094BCF
IC553 00D 963 0218 807 IC BU4094BCF
Q501C 00D 960 0196 603 TR KTC2874B
Q501FL 00D 960 0196 603 TR KTC2874B
Q501FR 00D 960 0196 603 TR KTC2874B
Q501SL 00D 960 0196 603 TR KTC2874B
Q501SR 00D 960 0196 603 TR KTC2874B
Q502C 00D 960 0196 205 TR KSA992F
Q502FL 00D 960 0196 205 TR KSA992F
Q502FR 00D 960 0196 205 TR KSA992F
Q502SBL 00D 960 0196 205 TR KSA992F
Q502SBR 00D 960 0196 205 TR KSA992F
Q502SL 00D 960 0196 205 TR KSA992F
Q502SR 00D 960 0196 205 TR KSA992F
Q503C 00D 960 0196 205 TR KSA992F
Q503FL 00D 960 0196 205 TR KSA992F
Q503FR 00D 960 0196 205 TR KSA992F
Q503SBL 00D 960 0196 205 TR KSA992F
Q503SBR 00D 960 0196 205 TR KSA992F
Q503SL 00D 960 0196 205 TR KSA992F
Q503SR 00D 960 0196 205 TR KSA992F
Q504C 00D 960 0196 506 TR KSC1845F
Q504FL 00D 960 0196 506 TR KSC1845F
Q504FR 00D 960 0196 506 TR KSC1845F
Q504SBL 00D 960 0196 506 TR KSC1845F
Q504SBR 00D 960 0196 506 TR KSC1845F
Q504SL 00D 960 0196 506 TR KSC1845F
Q504SR 00D 960 0196 506 TR KSC1845F
Q506SBL 00D 960 0196 603 TR KTC2874B
Q506SBR 00D 960 0196 603 TR KTC2874B
Q551 00D 960 0196 700 TR KTC3200BL
Q551T 00D 960 0097 003 TR KRA104M
Q552 00D 960 0196 302 TR KTA1268BL
Q552T 00D 960 0285 006 TR KRC104S
Q553 00D 963 0120 704 TR KRA102S
Q553T 00D 960 0097 003 TR KRA104M
Q554 00D 963 0120 704 TR KRA102S
Q554T 00D 960 0285 006 TR KRC104S
Q555 00D 963 0120 704 TR KRA102S
Q555T 00D 963 0255 802 TR KTC3199Y *
Q556 00D 963 0120 704 TR KRA102S
Q556T 00D 963 0121 004 TR KRC104M
Q557 00D 963 0121 606 TR KRC107S
Q557M 00D 963 0121 606 TR KRC107S
Q558 00D 963 0148 508 TR KTA1504S
Q558M 00D 963 0148 508 TR KTA1504S
Q559 00D 963 0120 704 TR KRA102S
Q561 00D 963 0120 704 TR KRA102S
Q562 00D 963 0120 704 TR KRA102S
Q563 00D 963 0120 704 TR KRA102S
Q564 00D 963 0120 704 TR KRA102S
Q912C 00D 963 0044 301 TR KTC2875B
Q912FL 00D 963 0044 301 TR KTC2875B
Q912FR 00D 963 0044 301 TR KTC2875B
Q912SBL 00D 963 0044 301 TR KTC2875B
Q912SBR 00D 963 0044 301 TR KTC2875B
Q912SL 00D 963 0044 301 TR KTC2875B
Q912SR 00D 963 0044 301 TR KTC2875B
Q912SW 00D 963 0044 301 TR KTC2875B
Q913C 00D 963 0044 301 TR KTC2875B
Q913FL 00D 963 0044 301 TR KTC2875B
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
