Denon AVR-2106 Service Manual

65
AVR-2106/886
DSP P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC801 00D 963 0237 503 JSR1165-C /OPTICAL
IC802 00D 963 0237 503 JSR1165-C /OPTICAL
IC803 00D 963 0237 503 JSR1165-C /OPTICAL
IC804 00D 262 3534 003 IC ADSP-21266SKSTZ-2B-E *
IC805 00D 262 3538 009 IC LH28F160BJE-BTL90 *
IC806 00D 262 3536 001 IC AS7C34096A-10TCN *
IC807 00D 262 3066 102 IC LC89057W-VF4-E(AC) +REF
IC808 00D 262 3535 002 IC AD1837AASZ *
IC809 00D 960 0266 805 IC MM74LCX244
IC810 00D 960 0266 805 IC MM74LCX244
IC811 00D 960 0266 805 IC MM74LCX244
IC812 00D 960 0266 902 IC MM74HCT244
IC814 00D 963 0218 904 IC MM74HCT00MTCX
IC815 00D 963 0218 904 IC MM74HCT00MTCX
IC815A 00D 963 0043 807 IC BA4510F
IC816 00D 262 2870 904 IC 74LVX157MTC +C
IC816A 00D 963 0043 807 IC BA4510F
IC817 00D 262 3536 001 IC AS7C34096A-10TCN *
IC817A 00D 963 0202 305 IC NJM2068M
IC818 00D 262 2642 909 IC SN74LV573APWR +REF
IC818A 00D 963 0202 305 IC NJM2068M
IC819 00D 262 2642 909 IC SN74LV573APWR +REF
IC819A 00D 963 0202 305 IC NJM2068M
IC820 00D 262 3339 907 IC SN74LVC139APWR +REF
IC820A 00D 963 0202 305 IC NJM2068M
IC821 00D 262 2870 904 IC 74LCX74MTC
IC822 00D 960 0296 008 IC CJ7805F
IC823 00D 963 0111 603 IC RC1117-3.3
IC824 00D 963 0147 509 IC RC1117-1.2
IC825 00D 262 2870 904 IC 74LCX74MTC
IC826 00D 963 0225 104 JST1165-B /OPTICAL
IC827 00D 963 0219 107 IC MM74HC151MTCX
IC828 00D 963 0219 000 IC 74VHCU04
IC829 00D 963 0244 907 IC SN74LV14APWR
Q804C 00D 960 0196 603 TR KTC2874B
Q804FL 00D 960 0196 603 TR KTC2874B
Q804FR 00D 960 0196 603 TR KTC2874B
Q804SBL 00D 960 0196 603 TR KTC2874B
Q804SBR 00D 960 0196 603 TR KTC2874B
Q804SL 00D 960 0196 603 TR KTC2874B
Q804SR 00D 960 0196 603 TR KTC2874B
Q804SW 00D 960 0196 603 TR KTC2874B
Q808 00D 963 0120 801 TR KRC102S
Q809 00D 963 0120 704 TR KRA102S
Q810 00D 963 0120 704 TR KRA102S
Q811 00D 963 0245 100 D, KDS226S
Q812 00D 963 0245 100 D, KDS226S
D803 00D 963 0219 709 D, 1N4148W
RESISTORS GROUP
R831 nsp 00D 963 0234 603 COIL,BEAD
R832 nsp 00D 963 0234 603 COIL,BEAD
R833 nsp 00D 963 0234 603 COIL,BEAD
