AVR-2106/886
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model (AVR-2106)
E3 : U.S.A. & Canada model (AVR-886)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
39A nsp 00D 963 0254 405 MAIN P.W.B. Ass'y 1 *
39 - MAIN P.W.B.
12 - SWITCH P.W.B.
15 - HEADPHONE P.W.B.
13 - POWER SWITCH P.W.B.
44 - VIDEO CNT P.W.B.
31A nsp 00D 963 0254 502 CPU P.W.B. Ass'y for AVR2106E3 1 *
31A nsp 00D 963 0255 103 CPU P.W.B. Ass'y for AVR886E3 1 *
31 - CPU P.W.B.
21 - FRONT P.W.B.
19 - FRONT OPTICAL P.W.B.
17 - FRONT S-VIDEO P.W.B.
18 - V.AUX P.W.B.
35 - INPUT-CNT P.W.B. for AVR2106E3
30A nsp 00D 963 0254 609 CNT P.W.B. Ass'y 1 *
30 - CNT P.W.B.
40 - PRE AMP P.W.B.
43 - VIDEO-PREOUT-CNT P.W.B.
42 - PRE OUT P.W.B.
45 - OUTLET P.W.B.
34A nsp 00D 963 0254 706 INPUT P.W.B. Ass'y for AVR2106E3 1 *
34A nsp 00D 963 0255 200 INPUT P.W.B. Ass'y for AVR886E3 1 *
34 - INPUT P.W.B.
37 - VIDEO P.W.B.
41 - COMPONENT P.W.B.
20 - MIC P.W.B.
32A nsp 00D 963 0254 803 EXT-IN P.W.B. Ass'y for AVR2106E3 1 *
32A nsp 00D 963 0255 307 EXT-IN P.W.B. Ass'y for AVR886E3 1 *
32 - EXT-IN P.W.B.
36A 00D 963 0254 900 DSP P.W.B. Ass'y 1 *
36 - DSP P.W.B.
54A nsp 00D 963 0255 006 2CH AMP P.W.B. Ass'y 1 *
54 - 2CH-AMP P.W.B.
1 00D 963 0214 704 WINDOW DISPLAY 1
2 00D 963 0152 303 KNOB INPUT for Black model 1
2 00D 963 0152 400 KNOB INPUT for Silver model 1
3 00D 963 0051 501 BADGE DENON for Black model 1
3 00D 963 0051 527 BADGE DENON for Silver model 1
4 00D 963 0229 304 LENS LED 2
5 00D 963 0152 604 KNOB VOLUME for Black model 1
5 00D 963 0152 701 KNOB VOLUME for Silver model 1
