Denon AVR-2106 Service Manual

62
AVR-2106/886
EXT-IN P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC201 00D 960 0174 104 IC CXA1511M
IC201X 00D 262 3517 907 IC F2602-01-TR
IC202 00D 262 3351 901 IC LMS202IMX +C for AVR2106E3
IC202X 00D 262 2517 908 IC SN74LV08APW-EL2 +REF
IC203 00D 262 3174 900 IC SN74AHCT08NS +C for AVR2106E3
IC203X 00D 262 2813 903 IC SN74AHCT08PW-EL2 +C
IC204 00D 960 0296 105 IC CJ7812F
IC204X 00D 963 0111 603 IC RC1117-3.3
IC205X 00D 262 3332 904 IC PCM1791ADBR +REF
IC206X 00D 963 0202 305 IC NJM2068M
IC207X 00D 263 1092 003 IC BA05T
IC208X 00D 963 0218 807 IC BU4094BCF
Q201RM 00D 960 0097 003 TR KRA104M
Q201RM1 00D 960 0097 003 TR KRA104M
Q201X 00D 960 0097 304 TR KRC102M
Q202 00D 963 0121 606 TR KRC107S for AVR2106E3
Q203 00D 963 0148 508 TR KTA1504S for AVR2106E3
Q203X 00D 960 0097 304 TR KRC102M
Q204X 00D 960 0097 304 TR KRC102M
Q205X 00D 960 0097 304 TR KRC102M
Q206X 00D 960 0097 207 TR KRA102M
Q207X 00D 960 0097 207 TR KRA102M
Q208X 00D 960 0196 603 TR KTC2874B
Q209X 00D 960 0196 603 TR KTC2874B
Q210X 00D 960 0196 603 TR KTC2874B
Q211X 00D 960 0196 603 TR KTC2874B
D201X 00D 963 0219 709 D, 1N4148W
D202X 00D 963 0219 709 D, 1N4148W
D203X 00D 963 0219 709 D, 1N4148W
D204X 00D 963 0219 709 D, 1N4148W
D205X 00D 963 0219 709 D, 1N4148W
D206X 00D 963 0219 709 D, 1N4148W
D207X 00D 963 0219 709 D, 1N4148W
ZD201RM 00D 960 0095 704 D,ZENER MTZJ6.2B
CAPACITORS GROUP
C201PC nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C201PFL nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C201PFR nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C201PSL nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C201PSR nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C201PSW nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C201X nsp 00D 963 9006 528 C,CERAMIC CHIP 20PF-J/50V
C202X nsp 00D 963 9006 528 C,CERAMIC CHIP 20PF-J/50V
C203RM nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C203X nsp 00D 963 9006 528 C,CERAMIC CHIP 20PF-J/50V
C204RM 00D 963 9005 749 C,ELECT 1UF-M/50V
C204X nsp 00D 963 9006 528 C,CERAMIC CHIP 20PF-J/50V
C205RM 00D 960 9008 653 C,FILM 0.012UF-J/100V
C205X nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C206RM 00D 963 9005 862 C,ELECT 47UF-M/16V
C206X nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C207RM 00D 960 9008 653 C,FILM 0.012UF-J/100V
C207X nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C208RM nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C208X 00D 963 9005 778 C,ELECT 10UF-M/50V
C209RM 00D 963 9005 749 C,ELECT 1UF-M/50V
C209X nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
