Denon AVR-2808 Service Manual

102
AVR-2808
1U-3839A A.VIDEO/VIDEO P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 00D 262 3756 904 LA73053-TLM-E
IC102,103 00D 262 3445 901 TC4051BFT
IC104,105 00D 262 3446 900 TC4052BFT
IC106,107 00D 262 3445 901 TC4051BFT
IC108 00D 262 3446 900 TC4052BFT
IC109,110 00D 262 3445 901 TC4051BFT
IC111-116 00D 263 1082 903 TK15420MTL +C
IC301,302 00D 263 1197 908 BU4094BCFV-E2
IC303 00D 262 3447 909 TC4053BFT
IC305 00D 262 3755 905 LA73062V-TLM-E
IC306 00D 262 2827 902 MM74HC4053SJ +C
IC307 00D 262 3749 908 LC74782M
IC308-310 00D 263 1082 903 TK15420MTL +C
IC501 00D 262 3551 002 NJW1321FP1
IC502 00D 263 1287 902 PQ090DNA1ZPH
IC503,504 00D 263 1225 906 NJM2581M-TE1
IC601-604 00D 263 1289 900 AZ4580MTR-E1
IC605 00D 263 0896 909 NJM2068MD-TE1 +C
IC606-615 00D 263 1289 900 AZ4580MTR-E1
IC616 00D 262 3739 002 APPA300
IC617 00D 262 3727 904 NJW1194V-TE1
IC618 00D 263 0896 909 NJM2068MD-TE1 +C
IC901-903 00D 263 1289 900 AZ4580MTR-E1
IC904 00D 262 3727 904 NJW1194V-TE1
TR101-103 00D 271 0312 905 KTA1504S-GR-RTK/P
TR104-109 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR301 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
TR302 00D 271 0312 905 KTA1504S-GR-RTK/P
TR303,304 00D 273 0464 901 KTC3875S-GR-RTK/P
TR501 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR502 00D 269 0144 905 DTC114YKA-T146 +C
TR503 00D 271 0312 905 KTA1504S-GR-RTK/P
TR601-607 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
TR608-631 00D 273 0460 905 KTC2875-B-RTK/P
D101-106 00D 276 0794 900 KDS160-RTK/P
D301,302 00D 276 0794 900 KDS160-RTK/P
D508,509 00D 276 0794 900 KDS160-RTK/P
RESISTORS GROUP
R101-112 00D 247 2019 928 RM73B--750FT
R120-125 00D 247 2019 928 RM73B--750FT
R147-152 00D 247 2045 918 RM73B--151FT_1608
R302-304 00D 247 2019 928 RM73B--750FT
R332-334 00D 247 2019 928 RM73B--750FT
R501-509 00D 247 2019 928 RM73B--750FT
R519-524 00D 247 2045 918 RM73B--151FT_1608
R555 00D 247 2045 921 RM73B--161FT_1608
R556 00D 247 2045 918 RM73B--151FT_1608
R557 00D 247 2045 921 RM73B--161FT_1608
R558 00D 247 2045 918 RM73B--151FT_1608
R559 00D 247 2045 921 RM73B--161FT_1608
R560 00D 247 2045 918 RM73B--151FT_1608
R561 00D 247 2045 921 RM73B--161FT_1608
R562 00D 247 2045 918 RM73B--151FT_1608
R563 00D 247 2045 921 RM73B--161FT_1608
R564 00D 247 2045 918 RM73B--151FT_1608
R565 00D 247 2045 921 RM73B--161FT_1608
R566 00D 247 2045 918 RM73B--151FT_1608
R567 00D 247 2045 921 RM73B--161FT_1608
R568 00D 247 2045 918 RM73B--151FT_1608
