Denon AVR-2808 Service Manual

114
AVR-2808
1U-3857A MAIN CPU P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101-103 00D 263 1286 903 PQ120DNA1ZPH
IC104 00D 262 3571 901 HIN202EIBNZ-T
IC105 00D GEN 8597 MAIN CPU SUB ASSY M30879FLBFP
IC106,107 00D 262 2375 904 IC, TC4094BF(TP1) +C
IC109 00D 263 1289 900 AZ4580MTR-E1
IC301 00D 262 3360 905 LC72722PM-TLM
IC302 00D 263 1289 900 AZ4580MTR-E1
IC501 00D 263 1242 918 NJM2831F06
IC502 00D 263 1035 002 PQ30RV11
z IC503 00D 268 0073 905 ICP-N15T
IC504 00D 263 1280 006 SI-8008HFE
IC505,506 00D 263 1288 901 PQ050DNA1ZPH
TR103 00D 271 0326 904 2SA1954(B)-TE85L
TR104 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR105-107 00D 273 0464 901 KTC3875S-GR-RTK/P
TR108 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
TR109 00D 269 0191 903 KRA104S-RTK/P (47K-47K)
TR110 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
TR111 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR112 00D 271 0326 904 2SA1954(B)-TE85L
TR115 00D 271 0326 904 2SA1954(B)-TE85L
TR116 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR301,302 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR303 00D 269 0086 908 DTA114TKT96 +C
TR304,305 00D 269 0066 902 DTC323TKT96 +C
TR501 00D 273 0464 901 KTC3875S-GR-RTK/P
TR507,508 00D 273 0464 901 KTC3875S-GR-RTK/P
TR509 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR512,513 00D 273 0468 907 KTC3199-GR-AT/P
D103,104 00D 276 0794 900 KDS160-RTK/P
D106,107 00D 276 0704 903 1SR35-400A(T93X)
D108 00D 276 0740 909 KDS184-RTK/P (K-COM)
D301-303 00D 276 0704 903 1SR35-400A(T93X)
D501 00D 276 0704 903 1SR35-400A(T93X)
D503-506 00D 276 0704 903 1SR35-400A(T93X)
D508 00D 276 0723 900 RB721Q-40
D510 00D 276 0850 705 RSX1001T3
D511 00D 276 0401 905 1SS133T77 (TAPE)
D512-521 00D 276 0704 903 1SR35-400A(T93X)
D522,523 00D 276 0855 001 D3SB20-7103
D526,527 00D 276 0401 905 1SS133T77 (TAPE)
ZD101 00D 276 0459 915 HZS5B-2TD
ZD501 00D 276 0464 900 HZS7A-1TD
ZD506 00D 276 0477 900 HZS16-1 TD(TAPE)
RESISTORS GROUP
R155,156 00D 241 2387 908 RD14B2E010JNBST
R512 00D 247 0046 948 RM73B--182DT
R514 00D 247 0047 992 RM73B--752DT
R515 00D 247 0045 965 RM73B--821DT
R516 00D 247 0044 982 RM73B--391DT
R517 00D 247 0047 921 RM73B--392DT
R529 00D 244 2671 930 RS14B3D200JNBST(S)
CAPACITORS GROUP
C106,107 nsp CK73B1E104KT +1608
C109,110 nsp CC73CH1H101JT +1608
C111 00D 254 4524 985 CE04W1H100MT SMG/RE3
ファームウエアをアップデート
するときは、SDI で最終バージョ
ンを確認して下さい。
サービス基板はアップデートし
て使用下さい。
WhenupdateFirmware,please
confirmalastversioninSDI.
Usetheserviceboardafter
updatingit.
