Denon AVR-2808 Service Manual

119
AVR-2808
PARTS LIST OF EXPLODED VIEW
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に"nsp" と記載されている基板 ASS'Y は供給できません。基板 ASS'Y の修理の際には基板部品表を確認のうえ、交換部品を発注してください。
＊ P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replace-
ment parts.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
2808BKE2 : Europe model(Black) 2808SRE2 : Europe model(Silver) 2808SPE2A : Asia model(Premium Silver)
Ref. No. Part No. Part Name Remarks Q'ty
Ne
w
1
00D 1U- 3838 A DIGITAL UNIT ASSY 1U-3838A 1 *
2
nsp A.AUDIO/VIDEO UNIT ASSY 1U-3839A *
2-1
A.VIDEO UNIT 1
2-2
AUDIO UNIT 1
2-3
ZONE UNIT 1
3
nsp FRONT UNIT ASSY 1U-3840A *
3-1
FLD UNIT 1
3-2
FUNC UNIT 1
3-3
FRONT IN UNIT 1
3-4
MIC UNIT 1
3-5
REMOTE/IPOD UNIT 1
3-6
DIGITAL I/O UNIT 1
3-7
V/D JOINT UNIT 1
3-8
UCON CONNECT UNIT 1
3-9
P.SW UNIT 1
3-11
FFC LOCK UNIT 1
4
nsp POWER REG. UNIT ASSY 1U-3841A *
4-1
REG UNIT 1
4-6
PRE AMP UNIT
4-7
AUDIO CONNECT UNIT 1
4-8
AUDIO LIMIT UNIT 1
4-9
LIMIT CONNECT UNIT 1
4-10
V-POWER JUNCTION UNIT 1
5
nsp POWER AMP UNIT ASSY 1U-3854A *
5-1
P.AMP UNIT 1
5-10
REG CONNECT UNIT 1
5-11
P.AMP HOLDER UNIT 1
6
nsp MAIN CPU UNIT ASSY 1U-3857A *
6-1
MAIN CPU UNIT 1
6-2
POWER UNIT 1
6-3
PRIM/CPU SUPPLY UNIT 1
6-4
UCON JUNCTION UNIT 1
11
00D 144 3030 034 FRONT PANEL 2808BKE2 1 *
11
00D 144 3030 018 FRONT PANEL 2808SRE2 1 *
11
00D 144 3030 021 FRONT PANEL 2808SPE2A 1 *
12
nsp DENON BADGE 1
13
nsp LENS 3
14
00D 144 3031 033 DOOR 2808BKE2 1 *
14
00D 144 3031 017 DOOR 2808SRE2 1 *
