AVR-2808
DISASSEMBLY
• Disassemble in order of the arrow of the figure of following flow.
下記フロー図の矢印の順番にはずしてください。
• In the case of the re-assembling, assemble it in order of the reverse of the following flow.
再組み立ての場合は、下記のフローの逆の順番に組立ててください
• In the case of the re-assembling, observe "attention of assembling" it.
再組み立ての場合は、「組立のご注意」を遵守してください。
TOP COVER SUB ASSY
FRONT UNIT ASSY BACK PANEL TRANS
Refer to "DISASSEMBLY : 1.FRONT UNIT ASSY" Refer to "DISASSEMBLY : 2.BACK PANEL ASSY" Refer to "EXPLODED VIEW"
and "EXPLODED VIEW" and "EXPLODED VIEW"
3-1 : FLD UNIT
3-2 : FUNC UNIT
1.DIGITAL UNIT ASSY
3-3 : FRONT IN UNIT
Refer to "DISASSEMBLY : 3.DIGITAL UNIT ASSY"
3-4 : MIC UNIT
and "EXPLODED VIEW"
3-5 : REMOTE/IPOD UNIT 1 : DIGITAL UNIT ASSY
3-6 : DIGITAL I/O UNIT 2-1 : A.VIDEO UNIT
3-7 : V/D JOINT UNIT 3-5 : DIGITAL I/O UNIT
3-8 : UCON CONNECT UNIT
3-9 : P.SW UNIT
2-2.AUDIO UNIT ASSY
3-11 : FFC LOCK UNIT
Refer to "DISASSEMBLY : 4.AUDIO UNIT"
and "EXPLODED VIEW"
2-2 : AUDIO UNIT
2-3 : ZONE UNIT
4-8 : AUDIO LIMIT UNIT
3-7 : UCON CONNECT UNIT
44.AM FM TUNER 6.MAIN CPU UNIT ASSY
Refer to "EXPLODED VIEW" Refer to "DISASSEMBLY : 9.MAIN CPU UNIT ASSY"
44 : AM FM TUNER
and "EXPLODED VIEW"
6-2 : POWER UNIT
3-4.REMOTE / IPOD UNIT
6-3 : PRIM/CPU SUPPLY UNIT
Refer to "EXPLODED VIEW"
6-4 : UCON JUNCTION UNIT
3-4 : REMOTE / IPOD UNIT
4.POWER REG. UNIT ASSY
Refer to "DISASSEMBLY : 7.POWER REG. UNIT ASSY"
and "EXPLODED VIEW"
4-1 : REG UNIT
4-6 : PRE AMP UNIT
4-7 : AUDIO CONNECT UNIT
4-8 : AUDIO LIMIT UNIT
4-9 : LIMIT CONNECT UNIT
4-10 : V-POWER JUNCTION UNIT
6-1.MAIN CPU UNIT
Refer to "DISASSEMBLY : 8.MAIN CPU UNIT"
and "EXPLODED VIEW"
6-1 : MAIN CPU UNIT
5.POWER AMP UNIT ASSY
Refer to "EXPLODED VIEW"
5-1 : P.AMP UNIT
5-10 : REG CONNECT UNIT
5-11 : P.AMP HOLDER UNIT
