Denon AVR-2808 Service Manual

14
AVR-2808
9. POWER AMP UNIT ASSY
Please refer to "EXPLODED VIEW" for the disassembly method of POWER AMP UNIT ASSY.
POWERAMPUNITASSY のはずしかたは "EXPLODEDVIEW" を参照してください。
10. MAIN CPU UNIT ASSY
(1) Disconnect the connector wires and remove the screws. ( コネクタワイヤーとねじをはずす。）
Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in MAIN CPU UNIT ASSY.
MAINCPUUNITASSYのはずしかたは "EXPLODEDVIEW" を参照してください。
11. TRANS
Please refer to "EXPLODED VIEW" for the disassembly method of TRANS.
TRANS のはずしかたは "EXPLODEDVIEW" を参照してください。
Proceeding (手順) : TOP COVER SUB ASSY → BACK PANEL
→ 1. DIGITAL UNIT ASSY → 2-2.AUDIO UNIT ASSY
→ 44.AM FM TUNER → 3-4.REMOTE/IPOD UNIT
→ POWER REG. UNIT ASSY → MAIN CPU UNIT
→ POWER AMP UNIT ASSY
Proceeding (手順) : TOP COVER SUB ASSY → BACK PANEL
→ 1. DIGITAL UNIT ASSY → 2-2.AUDIO UNIT ASSY
→ MAIN CPU UNIT ASSY
PRIM/CPU SUPPLY UNIT
PWB holder
Picture G
POWER UNIT
Picture G
CX022
CX512
CX021
POWER UNIT
Proceeding (手順) : TOP COVER SUB ASSY → TRANS
