Denon AVR-2808 Service Manual

109
AVR-2808
1U-3841A POWER REG. P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC701 00D 125 9006 090 UL TUBE
IC701 00D 279 0034 067 PTH9M04BB222TS2F333
IC801 00D 263 1100 034 KIA7815API-U/P
IC803 00D 263 1100 034 KIA7815API-U/P
TR101-114 00D 271 0301 903 KTA1268-BL-AT/P
TR115-121 00D 273 0471 907 KTC3206-Y-AT/P
TR401-408 00D 273 0460 905 KTC2875-B-RTK/P
TR413-420 00D 273 0460 905 KTC2875-B-RTK/P
TR501-508 00D 273 0460 905 KTC2875-B-RTK/P
TR701 00D 271 0301 903 KTA1268-BL-AT/P
TR704 00D 274 0160 907 2SD2144STPU
TR707 00D 271 0301 903 KTA1268-BL-AT/P
TR710 00D 273 0458 904 KTC3200-BL-AT/P
TR711-713 00D 271 0301 903 KTA1268-BL-AT/P
TR717 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
TR719 00D 271 0301 903 KTA1268-BL-AT/P
TR725 00D 273 0458 904 KTC3200-BL-AT/P
TR727 00D 271 0301 903 KTA1268-BL-AT/P
TR729 00D 274 0160 907 2SD2144STPU
TR735,736 00D 271 0301 903 KTA1268-BL-AT/P
TR801 00D 274 0198 005 KTD998-O-U/P
TR802 00D 272 0158 007 KTB778-O-U/P
TR803 00D 273 0468 907 KTC3199-GR-AT/P
TR804 00D 271 0311 906 KTA1267-GR-AT/P
TR805 00D 272 0158 007 KTB778-O-U/P
TR806 00D 274 0198 005 KTD998-O-U/P
TR807 00D 273 0469 906 KTC3209-Y-AT/P
TR808 00D 271 0313 904 KTA1281-Y-AT/P
TR809 00D 273 0468 907 KTC3199-GR-AT/P
TR810,811 00D 271 0311 906 KTA1267-GR-AT/P
TR812 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
D101-114 00D 276 0723 900 RB721Q-40
D701 00D 276 0401 905 1SS133T77 (TAPE)
D706 00D 276 0401 905 1SS133T77 (TAPE)
D709 00D 276 0460 904 HZS5C-1TD
D806 00D 276 0855 001 D3SB20-7103
D807,808 00D 276 0704 903 1SR35-400A(T93X)
ZD806,807 00D 276 0464 900 HZS7A-1TD
ZD808,809 00D 276 0468 906 HZS9B-1TD
RESISTORS GROUP
R129-135 00D 241 2380 905 RD14B2E122JNBST
R143-149 00D 241 2376 964 RD14B2E470JNBST
R714 00D 241 2383 902 RD14B2E223JNBST
R742 00D 241 2383 902 RD14B2E223JNBST
R748 00D 244 2055 996 RS14B3A122JNBST(S)
R750,751 00D 244 2055 996 RS14B3A122JNBST(S)
R813,814 00D 244 2050 988 RS14B3A202JNBST(S)
CAPACITORS GROUP
C101 00D 254 4586 949 CE04W2A100MT(RA3)
C102-108 00D 254 4802 924 CE04W1J470MT(RA3)
C109-115 00D 255 1273 944 CQ93M1H221KT(B)
C116-122 00D 255 1264 940 CQ93M1H222JT(B)
C123-129 00D 255 1273 944 CQ93M1H221KT(B)
C130-136 00D 254 4802 908 CE04W1J101MT(RA3)
C137-143 00D 257 0523 934 CC73CH2A330JT +1608
C401-408 00D 254 4586 936 CE04W2A4R7MT(RA3)
