Restoring All the Settings to as They were at the
Time of Purchase (Resetting the Microprocessor)
Perform this procedure if the display is abnormal or if operations cannot be performed.
When the microprocessor is reset, all the settings are reset to their default values.
1
Turn off the power using <POWER>.
2
Press <POWER> while simultaneously pressing <STANDARD> and <DSP
SIMULATION>.
3
Once the display starts ashing at intervals of about 1 second, release the two
buttons.
If in step 3 the display does not flash at intervals of about 1 second, start over from step 1.
Specifications
• Digital
D/A output:
Rated output — 2 V (at 0 dB playback)
Total harmonic distortion — 0.008 % (1 kHz, at 0 dB)
S/N ratio — 102 dB
Dynamic range — 100 dB
Digital input:
Format — Digital audio interface
• Phono equalizer (PHONO input — REC OUT)
Input sensitivity:
2.5 mV
RIAA deviation:
±1 dB (20 Hz to 20 kHz)
S/N:
74 dB (A weighting, with 5 mV input)
Rated output:
150 mV
Distortion factor:
0.03 % (1 kHz, 3 V)
n
Video section
• Standard video connectors
Input / output level and impedance:
1 Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 10 MHz — +0, –3 dB (when video convert set to “OFF”)
• S-Video connectors
Input / output level and impedance:
Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
C (color) signal — 0.3 (PAL) / 0.286 (NTSC) Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 10 MHz — +0, –3 dB (when video convert set to “OFF”)
• Color component video connector
Input / output level and impedance:
Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
P
B / CB signal — 0.7 Vp-p, 75 Ω/ohms
P
R / CR signal — 0.7 Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 100 MHz — +0, –3 dB (when video convert set to “OFF”)
n
Tuner section [FM] [AM]
(note: µV at 75 Ω/ohms, 0 dBf = 1 x 10
-15
W)
Receiving Range: 87.5 MHz ~ 108.0 MHz 522 kHz ~ 1611 kHz
Usable Sensitivity: 1.0 µV (11.2 dBf) 20 µV
50 dB Quieting Sensitivity: MONO 1.6 μV (15.3 dBf)
STEREO 23 μV (38.5 dBf)
S/N (IHF-A): MONO 77 dB
STEREO 72 dB
Total harmonic Distortion (at 1 kHz): MONO 0.15 %
STEREO 0.3 %
n
General
Power supply: AC 230 V, 50 Hz
Power consumption:
670 W
0.1 W (Standby)
Maximum external dimensions:
434 (W) x 171 (H) x 414 (D) mm
Weight: 12.9 kg
n
Main remote control unit (RC-1118)
Batteries: R6/AA Type (two batteries)
Maximum external dimensions:
52 (W) x 243 (H) x 21 (D) mm
Weight: 184 g (including batteries))
n
Sub remote control unit (RC-1121)
Batteries: R03/AAA Type (two batteries)
Maximum external dimensions:
49 (W) x 220 (H) x 24.5 (D) mm
Weight: 114 g (including batteries)
b
For purposes of improvement, specifications and design are subject to change without notice.
n
Audio section
• Power amplifier
Rated output:
Front:
120 W + 120 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
160 W + 160 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Center:
120 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
160 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround:
120 W + 120 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
160 W + 160 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround back:
120 W + 120 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
160 W + 160 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Dynamic power:
130 W x 2ch (8 Ω/ohms)
180 W x 2ch (4 Ω/ohms)
Output connectors:
Center, Surround, Surround back: 6 ~ 16 Ω/ohms
Front: A or B
6 ~ 16 Ω/ohms
A + B
8 ~ 16 Ω/ohms
• Analog
Input sensitivity / Input impedance:
200 mV / 12 kΩ/kohms (except for EXT. IN (SW, S, SB), CD, PHONO, V. AUX)
200 mV / 47 kΩ/kohms (EXT. IN (SW, S, SB), CD, PHONO, V. AUX)
Frequency response:
10 Hz ~ 100 kHz +1, –3 dB (DIRECT mode)
S/N:
102 dB (IHF–A weighted, DIRECT mode)
Distortion:
0.005 % (20 Hz ~ 20 kHz) (DIRECT mode)
Rated output:
1.2 V
