ENGLISH
For buttons not explained here, see the page indicated in parentheses ( ).
Part Names and Functions
t
q
w
e
r
Q5 Q6Q4Q3
y
o
Q0
Q1
Q2
ui
W5
Q7
Q8
Q9
W0
W1 W4W3W2
E1
E6
W9E0
E4E5
E2
E3
W8
W7 W6
q Power operation button ····························(23)
w Power indicator ··········································(23)
e Power switch ·············································· (23)
r Door
When you are using buttons and/or terminals
behind the door, press the bottom of the door to
open it. When not using buttons and/or terminals
behind the door, close it. Be careful not to catch
your fingers when closing the door.
t QUICK SELECT buttons ·····························(77)
y MASTER VOLUME control knob ··············· (62)
u AUDYSSEY
DYNAMIC VOLUME™ indicator ················ (69)
i HD AUDIO indicator ····································(65)
o Master volume indicator
Q0 Display
Q1 Remote control sensor ································ (3)
Q2 SOURCE SELECT knob ······························ (26)
Q3 SOURCE button ·········································· (26)
Q4 TUNING PRESET button ···························· (52)
Q5 ZONE 2/3 / REC SELECT button ··········(74, 82)
Q6 VIDEO SELECT button ······························· (46)
GWith the door openH
W7 MULTEQ
®
button ······································· (69)
W8 DYNAMIC VOLUME™ button (DYN VOL) ··· (70)
W9 USB port ······················································ (20)
E0 STATUS button ··········································(73)
E1 AUDIO DELAY button ································(71)
E2 RESTORER button ······································ (71)
E3 DIRECT/STEREO button ····························(65)
E4 PURE DIRECT button ································· (66)
E5 DSP SIMULATION button ·························· (65)
E6 STANDARD button ····································· (64)
Front Panel
Q7 Headphones jack ········································(62)
Q8 ZONE2 ON/OFF button ······························ (82)
Q9 ZONE3 ON/OFF button ······························ (82)
W0 FRONT SPEAKERS button ························· (62)
W1 MENU button ·············································· (24)
W2 Cursor buttons (uio p) ·························· (25)
W3 ENTER button ············································· (25)
W4 RETURN button ·········································· (25)
W5 V.AUX INPUT connectors ·························· (20)
W6 SETUP MIC jack ·········································· (28)
Getting Started

Denon AVR-3310 Specifications

General

Equalizer	Yes
Product color	Black
Frequency range	10 - 100000 Hz
Total Harmonic Distortion (THD)	0.05 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Connectivity technology	Wired
Headphone connectivity	3.5 mm
S-Video outputs quantity	2
Digital audio optical out	1
S-Video inputs quantity	7
Digital audio optical in	3
Dimensions (WxDxH)	434 x 414 x 171 mm
HDMI ports quantity	5
Power consumption (standby)	1 W
Power consumption (typical)	780 W

Weight and Dimensions

Weight	12900 g
