DIRECT STEREO DOLBY / DTS
WIDE
SCREEN
5CH / 7CH
STEREO
DSP
SIMULATION
SURROUND MODE
(Main unit)
The surround mode switches in the following order
each time the DSP SIMULATION button is pressed:
WIDE SCREEN SUPER STADIUM ROCK ARENA
JAZZ CLUB CLASSIC CONCERT
MONO MOVIE
MATRIX
DSP surround simulation
1
Select the surround mode for the input channel.
2
Display the surround parameter screen on the monitor.
The screen for the selected surround mode
appears.
(Main unit)
3
Set the parameters.
(Main unit)
4
Press the SURR. PARA. button to complete the setting.
NOTES:
• When “Default” is selected and the F cursor button is pressed, “CINEMA EQ.” and “D. COMP.” are
automatically set to “OFF”. In addition, “ROOM SIZE” is set to “medium”, “EFFECT LEVEL” to “10” and
“DELAY TIME” to “30ms”.
• The “ROOM SIZE” expresses the expansion effect for the different surround modes in terms of the size
of the sound field, not the actual size of the listening room.
B To select Bass or Treble. B To set the level.
Tone control setting
• Use the tone control setting to adjust the bass and treble as desired.
1
Display the surround parameter
screen on the monitor.
The screen for the selected
surround mode appears.
“TONE” cannot be selected
in the Direct or Home THX
Cinema mode.
(Remote control unit)
2
Select “TONE”.
(Remote control unit)
3
Switch to the Tone Control
screen.
(Remote control unit)
4
If you do not want the tone
to be adjusted, set “Tone
Defeat” to “ON”. (See page
24.)
(Remote control unit)
5
Enter the setting.
The surround menu screen re-appears.
(Remote control unit)
(Remote control unit)
“WIDE SCREEN” is not displayed when the
operation is performed with the buttons on the
main unit.
(Remote control unit)
(Remote control unit)
(Remote control unit)
(Remote control unit)
6
Press the SURR. PARA. button to complete the setting.
(Remote control unit)
