REMOTE
Connect this connector to the RC-37 control unit
using the included control cord.
Voltage Selector (multi-voltage model only)
On multi-voltage models, use this to
select the
power voltage. Always disconnect the power plug
before changing the voltage.
(4)
RC-37 (Control Unit) Rear Panel
Control Connector
Connect this connector to the REMOTE connector on
the DN-2700F (main unit) using the included control
cord.
(5)
LCD
TRACK, MINUTE, SECOND and FRAME
Displays
These displays indicate information on the current
position and time.
MEMORY Displays
These indicate the memory location number during
programming or memory playback.
FINE Indicators
These indicate whether the jog dial resolution is at
±1 frame (FINE) or ±10 frames.
BAR Indicator
These ten indicators provide
a
visual display of the
approximate position of the pickup within the cur-
rent track.
ELAPSED Indicators
These indicate that the time shown on the display is
the elapsed time.
REMAIN Indicators
These indicate that the time shown on the display is
the remaining time.
SINGLE Indicators
When these indicators are lit, playback will stop at
the end of the track.
CONTINUE Indicators
When these indicators are lit, playback will continue
until the end of the disc.
RANDOM Indicators
These blink during preparation for random playback
and are lit solid during random playback.
MEMORY and PLAY Indicators
The MEMORY indicators light or blink when data has
been stored in the memory. The PLAY indicators
light during memory playback.
END Indicators
These indicators light during programming when
the END button is pressed.
1
1
Pitch Sliders
Use these sliders to adjust the BPM. Slide up to
decrease the BPM, down to increase the BPM.
PITCH Buttons
Use these buttons to enable or disable pitch adjust-
ment using the pitch sliders. Pitch adjustment with
the pitch slider is enabled when the PITCH LED is lit.
4%, 8% and 50% Buttons
Use these buttons to select the range of pitch
adjustment with the pitch sliders.
PITCH BEND- and PITCH BEND+ Buttons
The pitch changes temporarily while these buttons
are pressed. Release the buttons to return to the
original BPM.
BEAT Indicators
These indicate the beat of the music currently
playing.
1 and 2 Buttons
Use these buttons to select which player the number
buttons will function for.
CALL Button
Press this button to display the contents of the
memory steps in sequence.
END Button
Press this button during programming to enter the
END point data for the current memory step. END
point data may be entered using the number buttons
or the Jog/Shuttle dials. When pressed, the END
i
ndicator on the LCD lights.
CLEAR Button
Press this button to clear the data which was input
using the number buttons.
0 ~ 9 Buttons (Number Buttons)
Use these buttons to input track numbers and times
(
minutes and seconds).
RANDOM Button
Press this button to prepare the player for random
playback.
STORE Button
Use this button to store previously entered START
and/or END point data into memory.
MEMORY CUE Button
Use this button to cue each disc to its first memory
step.
DN-2700F (Main Unit) Rear Panel
LINE OUT 1 and 2
The audio signals from each player are output from
these jacks.
To Next Page
