PARTS LIST OF EXPLODED VIEW
Ref. No Part No Parts Name Q'ty Remarks
Others
1 928 0150 014 TOP COVER 1
2 9MV HD06 90 SCREW 8
3 9MV HD10 41 SCREW 4
4 928 0150 108 LEG 2
6 928 0050 402 SCREW 2
7 928 0150 205 FOOT RUBBER 2
9 9MR EP31 56D MOTHER P.C.B. 1
9-1 928 0168 608 FL HOLDER 1
12 9MV HD14 03 SCREW 6
13 9MR EP33 78A MODULE P.C.B. 1
14 9MR EZ13 54 FLEXIBLE CABLE(38P) 1
15 9MR EZX10 57 CONNECTOR CABLE(2P) 1
17 928 0038 152 SCREW 4
18 928 0167 214 TRAY TOP 1
19 928 0167 311 FRONT PANEL ASS'Y1 1
19-1 928 0167 418 POWER BUTTON 1
19-2 928 0167 515 FUNCTION BUTTON 1
19-3 928 0167 609 INDICATOR PIECE 2
19-4 928 0167 722 MAIN BUTTON 1
20 928 0172 005 FRONT1 P.C.B. 1
25 928 0146 109 SCREW 12
26 9MR MC04 41 EARTH SPRING(A) 1
27 928 0171 608 EARTH SPRING(B) 2
28 9MR MC04 60 EARTH PLATE 1
35 9MV GU73 96 VOLUME KNOB 1
36 9MR MC04 59 EARTH SPRING(C) 1
37 928 0167 900 FRONT2 P.C.B. 1
38 928 0168 006 FRONT3 P.C.B. 1
101 9MR XQ07 42B SPINDLE MOTOR ASS'Y 1
102 928 0151 000 MIDDLE CHASSIS 1
103 9MR MS07 12 FIXED PIN 3
106 928 0159 002 INTERMEDIATE P.C.B. 1
106-1 928 0151 301 PCB RUBBER 1
107 9MR HD20 060 SCREW 1
108 928 0151 204 FLOATING RUBBER 4
112 9MR DG04 99 TRAVERSE GEAR(A) 1
113 9MR MC04 15 ADJUST SPRING HOLDER1 3
116 9MR ME03 20 ADJUST SPRING 3
119 9MR MM02 34 TRAVERSE DRIVE RACK 1
120 928 0169 005 DRIVE SHAFT 1
121 928 0169 102 GUIDE SHAFT 1
122 9MR HD17 036 SCREW 2
123 9MV VHD12 24 SCREW 4
124 9MR DG05 00 TRAVERSE GEAR(B) 1
125 9MR DG05 01 TRAVERSE GEAR(C) 1
126 9MR ME03 19 TRAVERSE GEAR SPRING 1
128 928 0169 209 TRAY 1
