5
4.1. Operating instructions
4 General Description
1 On/standby switch (POWER)
Press to switch the unit from on to standby mode or vice versa.
In standby mode, the unit is still consuming a small amount of
power.
2 Stop button (∫ STOP)
3 Still/Pause button (; STILL/PAUSE)
4 Skip buttons (:, 9 SKIP)
5 Top menu button (TOP MENU)
6 Cursor buttons (3, 4, 2, 1)/Enter button (ENTER)
7 Display button (DISPLAY)
8 Subtitle button (SUBTITLE)
9 Play mode button (PLAY MODE)
: Repeat mode button (REPEAT MODE)
; A-B repeat button (A-B REPEAT)
< Cinema button (CINEMA)
= Setup button (SET UP)
> Clear button (CLEAR)
? Group button (GROUP)
@ Headphone V.S.S. button (HP V.S.S.)
A Open/close button (OPEN/CLOSE)
B Play button (1 PLAY)
C Slow/Search buttons (6, 5 SLOW/SEARCH)
D Menu button (MENU)
E Return button (RETURN)
F Audio button (AUDIO)
G Angle button (ANGLE)
H Numbered buttons (1–9, 0, S10)
I Audio only button (AUDIO ONLY)
J Page button (PAGE)
K Speaker V.S.S. button (SP V.S.S.)
L Audio only indicator
M Disc tray
N Headphone jack (PHONES)
O Headphone level control (PHONES LEVEL)
P Display
Q Standby indicator (STANDBY)
When the unit is connected to the AC mains supply, this indicator
lights up in standby mode and goes out when the unit is turned
on.
R Progressive scan button/indicator
(PROGRESSIVE SCAN)
Buttons such as 2 function the same as the controls on the remote
control.
PCM AUDIO TECHNOLOGY / DVD AUDIO / VIDEO PLAYER DVD-1600
STANDBY
GROUP
OPEN/CLOSE PLAY
SKIP SLOW / SEARCH
STILL / PAUSE STOP
PHONES PHONES LEVEL
HP V.S.S. AUDIO ONLY
MIN MAX
AUDIO
/
VIDEO
ON / STANDBY
REMOTE SENSOR
1
N
O P Q ? R 4 C
@
M A B 3 2IL
PROGRESSIVE SCAN
ENTER
POWER
STOP
STILL / PAUSE
PLAY
OPEN/CLOSE
SKIP
TOP MENU
MENU
DISPLAY
RETURN
GROUP PAGE
AUDIO ONLY
HP V.S.S. SP V.S.S.
6:9 5
∫;
SLOW / SEARCH
PLAY MODE SUBTITLE
AUDIO ANGLE
123
A-B REPEAT
456
789
SET UP
CLEAR
0
S
10
CINEMA
REPEAT MODE
1
REMOTE CONTROL UNIT
RC-551
AUDIO
/
VIDEO
1A
B
D
G
H
I
J
K
E
F
C
4
@
2
5
6
9
:
;
<
=
7
>
?
8
3
