4
DVD-3910
DISASSEMBLY
(Follow the procedure below in reverse order when reas-
sembling.)
分解と廃棄(Disassembly and abandonment)
No. Part Name Q’ty Material Weight No. Part Name Q’ty Material Weight
ｃ･1 Loader Panel ass’y (1) - 15g ｍ･1 Top cover (1) SECC+PVC 1,325g
ｃ･2 DVD mechanism ass’y (1) - 1,053g ｍ･2 Front angle (1) SECC 147g
ｃ･3 Power P.W.B. ass’y (1) - 297g ｍ･3 Ieee1394 top Shield (1) SPCC 57g
ｃ･4 Ac inlet (1) - 9g ｍ･4 Ieee1394 bottom Shield (1) SECC 92g
ｃ･5 Ferrite core & 3P VH wire (1) - 34g ｍ･5 Rear panel (1) SECC 300g
ｃ･6 Video P.W.B. ass’y (1) - 154g ｍ･6 Mecha base (1) SECC 805g
ｃ･7 Scart P.W.B. ass’y (1) - 40g ｍ･7 Bottom cover (1) SECC 1,750g
ｃ･8 Audio P.E.B. ass’y (1) - 166g ｍ･8 Chassis (1) SECC 1,730g
ｃ･9 IEEE1394 P.W.B. ass’y (1) - 84g ｍ･9 Spring (1) SUS304 1g
ｃ･10 System P.W.B. ass’y (1) - 215g ｍ･
10
Front panel (1) A6063SS 345g
ｃ･11 D12mm knob ass’y (1) - 3g ｍ(Metals) totals 6,553g
ｃ･12 Display P.W.B. ass’y (1) - 128g
ｃ･13 Power-1 P.W.B. ass’y (1) - 15g No. Part Name Q’ty Material Weight
ｃ･14 Power knob(MAIN) ass’y (1) - 1g ｓ･1 Screw 3X6 CBTS(S)-B (48) SW 25g
ｃ･15 Power-2 P.W.B. ass’y (1) - 7g ｓ･2 Screw 4X8 3P
SWELLING
(9) SW 15g
ｃ･16 Power knob(SUB) ass’y (1) - 2g ｓ･3 Screw 3X8 CBTS(S)-Z (26) SW 16g
ｃ Wire ( the othes ) (1) - 49g ｓ･4 Screw 3X8 CBS-Z (2) SW 1g
ｃ(Complex) totals 2,272g ｓ･5 Screw 3X8 CFTS(S) (2) SW 1g
ｓ･6 Screw 3X8 FIXING (8) SW 6g
No. Part Name Q’ty Material Weight ｓ･7 Ｐ3 nut for DVI (2) SW 2g
ｐ･1 P.W.B. support (1) PA66 1g ｓ･8 Ｐ3 nut for RS-232C (2) SW 2g
ｐ･2 Foot ass’y (4) ABS 82g ｓ･9 Screw 3X8 CBTS(P)-B (16) SW 9g
ｐ･3 P.W.B. spacer (6) PA66 2g ｓ･
10
Screw 3X10 Special (2) SW 3g
ｐ･4 Lens (1) PMMA 1g ｓ Washer (2) SPCC/SK 1g
ｐ･5 Blind ass’y (1) PVC+ 8g ｓ(Screws) totals 81g
ｐ･6 Inner panel ass’y (1) ABS 261g
ｐ･7 Part of inner panel (1) ABS 4g Total-Weight 9,270g
ｐ･8 Rubber sheet (2) CR 3g Single-material Weight 6,998g
ｐ･9 Rubber sheet (1) CR 2g Complex-material Weight 2,272g
ｐ(Plastics) totals 364g
(1)Disassembly of a set
It decomposes according to a work procedure 1.〜11.
clause.
(2)Judgment of use parts
It classifies according to the discernment signs in a
figure (c, m, s, p, etc.).
(3)Abandonment of parts
Each part article is discarded according to the
specification abandonment method of each
self-governing body.
(1)セットの分解
作業手順 1.〜11.項に従い分解を実施します。
(2)使用部品の分別
図中の識別記号(c,ｍ,ｓ,ｐ等)に従い分別する。
(3)部品の廃棄
各部品は、各自治体の指定廃棄方法に従い廃棄する。
各部のはずしかた
（組み立てるときは、逆の順序で行ってください。）
