45
DVD-3910
ES6138F Pin Description
Name Pin Numbers I/O Definition
VEE 1,18, 27, 59, 68, 75,
92, 99, 104, 130,
148, 157, 159, 164,
183, 193, 201
P I/O power supply.
LA[21:0]
2:7, 10:16, 19:23,
204:207
O RISC port address bus.
VSS 8, 17, 26, 34, 43,
60, 67, 76, 84, 91,
98, 103, 120, 129,
138, 147, 156, 163,
171, 177, 184, 192,
200, 208
G Ground.
VCC
9, 35, 44, 83, 121,
139, 172
P Core power supply.
RESET# 24 I Reset input (active-low).
TDMDX
25
O TDM transmit data output.
RSEL I LCS3 ROM Boot Data Width Select. Strapped to VCC or ground via 4.7-kΩ
resistor; read only during reset.
TDMDR 28 I TDM receive data input.
TDMCLK 29 I TDM clock input.
TDMFS 30 I TDM frame sync input.
TDMTSC# 31 O TDM output enable (active-low).
TWS
32
O Audio transmit frame sync output.
SEL_PLL2 I System and DSCK output clock frequency selection is made at the rising edge of
RESET#. The matrix below lists the available clock frequencies and their
respective PLL bit settings. Strapped to VCC or ground via 4.7-kΩ resistor; read
only during reset.
RSEL Selection
0 16-bit ROM
1 8-bit ROM
SEL_PLL2 SEL_PLL1 SEL_PLL0 PLL Settings
0 0 0 DCLK × 4.5
001DCLK × 5.0
0 1 0 Bypass
011DCLK × 4.0
1 0 0 DCLK × 4.25
1 0 1 DCLK × 4.75
110DCLK × 5.5
111DCLK × 6.0
