Delay
Delay is an effect that will record a portion of the incoming signal, and then play it back a short
time later. The recording can repeat just once or several times.
Delay Model - Knob 1 selects one of the 5 different Delay models. Values include: 
(DigiTech
®
Analog Delay),  (DigiTech Digital Delay),  (DigiTech Modulated Delay), 
(DigiTech Pong Delay), and  (DigiTech Tape Delay). Press this knob to turn the Delay mod-
els on and off.
Knobs 2, 3, and 4 have the following functions for the various Delay models:
Delay
Model
Knob 2
(Time)
Knob 3
(Repeats)
Knob 4
(Level)
P4
(X-Edit
TM
only)
P5
(X-Edit
only)

Time Repeats Delay Level -- --

Time Repeats Level Duck Thresh Duck Level

Time Repeats Delay Level Depth --

Time Repeats Delay Level Duck Thresh Duck Level

Time Repeats Level Wow Flutter
Reverb
Using reverb in recorded program material gives the listener a sense that the material is being per-
formed in an actual room or hall. It is this similarity to actual acoustic spaces that makes reverber-
ation a useful tool in recorded music. The RP150 features genuine Lexicon
®
reverbs, whose rich,
lush effects have been heard in countless songs, soundtracks, and live performances for decades.
Reverb Model
Knob 1 selects the Reverb model or acoustic space. Press this knob to turn the Reverb
models on and off. The following models are available:
- Based on a Fender
®
Twin Reverb
- Lexicon
®
Ambience
- Lexicon Studio
- Lexicon Room
- Lexicon Hall
- Based on an EMT240 Plate
Reverb
Model
Knob 2
(Decay)
Knob 3
(Liveliness)
Knob 4
(Reverb
Level)
P4
(X-Edit
TM
only)

-- -- Reverb --

Decay Liveliness Reverb Level Predelay

Decay Liveliness Reverb Level Predelay

Decay Liveliness Reverb Level Predelay

Decay Liveliness Reverb Level Predelay

Decay Liveliness Reverb Level Predelay

DigiTech RP 150 Specifications

General

Expression Pedal	Yes
Drum Machine	No
A/D/A Converter	24-bit
Sampling Frequency	44.1 kHz
Type	Guitar Effects Processor
Inputs	1 x 1/4" Instrument
Power Supply	9V DC (included)
