DigiTech RP 150 User Manual

38
39
Specifications
General Specifications
A/D/A Converter: 24-bit high performance audio
Sampling Frequency: 44.1 kHz
DSP Section: AudioDNA2™ DSP Processor
Simultaneous Effects: 11
Preset Memory: 50 User Presets (1-50) / 50 Factory Presets (51-00)
Drum Machine: 60 Patterns
Dimensions: 10 5/8" Length x 8 3/4" Width x 2 5/8" Height
Unit Weight: 3.2 lbs.
Analog Input Connections:
Guitar Input: 1/4" Unbalanced (TS)
Input Impedance: 500k Ohms
Control In: 1/4" Unbalanced
Analog Output Connections:
Left/Right Outputs: 1/4" Unbalanced
Left/Right Output Impedance: 500 Ohms per side
Maximum Output: +10dBu
Headphones: 1/8" Stereo (TRS) – 13.6mW per channel @ 50 Ohms
Section 5 - Appendix
Digital Connections:
Universal Serial Bus (USB): Type B, supports USB1.1 Full Speed (12 Mbps Bandwidth USB 2.0 compatible)
RP150 USB Recording Specifications:
Sample Rate: 44.1 kHz
Bit depth: supports 16-bit or 24-bit (depends on setup in Recording Software)
Power Requirements:
US and Canada: 120 VAC, 60 Hz Adapter: PS0913B-120
Japan: 100 VAC, 50/60 Hz Adapter: PS0913B -100
Europe: 230 VAC, 50 Hz Adapter: PS0913B -230
UK: 240 VAC, 50 Hz Adapter: PS0913B -240
Minimum Windows® PC Computer System Requirements:
Windows® XP w/Service Pack 2 and .NET Framework 2.0 installed
500 MHz processor speed (1.2 GHz recommended)
512 MB RAM (1GB recommended)
Minimum Mac Computer System Requirements:
OS 10.4 or higher
Power PC or Intel
®
G4/G5 Processor
800 MHz processor speed (1.2 GHz recommended)
512 MB RAM (1GB recommended)
