Dini Argeo 3590EXP Series User Manual

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF09_02_13.01_EN_U
20
5.1 WEIGHT ZOOM (available only on CPWE and CPWET models)
The zoom function allows to increase the size of the weight digits, in order to ease the reading from a distance; with the
active zoom, the data is shown on a single line.
Through the << ZOOM.W >> step, one can disable/enable the function and set a delay which determines the activation
mode:
- Always active function (with delay equal to 0), or
- Disabled function at the pressing of a key and re-enabled automatically when the keyboard inactivity time reaches the
configured delay period (with delay greater than 0).
5.2 STATUS INDICATORS
LED
FUNCTION
POWER
Indicates the type of indicator power supply:
- red pilot light: through built-in power adapter;
- green pilot light: through battery (charged battery);
- pilot light off: through battery (discharged battery).


0


Indicates that the weight detected by
the weighing system is near zero, including the interval of 1/4 +1/4
of the scale’s division.
~
Indicates that the weight is unstable.
NET Indicates that the weight shown by the LED display is a NET WEIGHT.


T

 Indicates that a tare value has been acquired or entered.
g Indicates that the unit of measure in use is the gram.
kg Indicates that the unit of measure in use is the kilogram.
t Indicates that the unit of measure in use is the ton.
PCS Not used in this application
F Indicates that an axle totalization cycle is in execution.
START Not used in this application
STOP Not used in this application.
W1 W2 W3 See section 8.
SP1
Not used in this application
SP2
Not used in this application
CUS MAT VEH
