Dini Argeo 3590EXP Series User Manual

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF09_02_13.01_EN_U
5
2. MAIN TECHNICAL SPECIFICATIONS
POWER SUPPLY
3590E
:
- 12 Vdc ( 8 ÷ 36 Vdc in the IO versions), with internal 100 ÷ 240 Vac (50÷60 Hz)
/ 12 Vdc adapter.
- 6 Vdc from rechargeable built-in battery, fitted depending on the model.
CPWE:
- 8 ÷ 2436 Vdc
- 6 Vdc from external rechargeable battery (upon request).
CPWET:
12 Vdc with external 100 ÷ 240 Vac (50÷60 Hz) / 12 Vdc adapter.
6 Vdc from external rechargeable battery (upon request).
MAXIMUM POWER
16 VA.
OPERATING TEMPERATURE
From
-
10 to +40 °C.
CONVERTER
24 bit Sigma Delta.
CONVERSION SPEED
200 conv./sec with automatic selection.
RANGE OF INPUT SIGNAL
0,6 mV/V
-
3,2 mV/V.
MINIMUM VOLTAGE PER DIVISION
0.3
µ
V (approved instrument); 0.03
µ
V (non-approved instrument).
AUTOMATIC ZERO DETECTION
Only in gross mode
, programmable at +/
-
¼, ½, 1, 2 divisions.
ZERO RANGE
Configurable up t
o +/
-
50
%
of max load capacity.
AUTO ZERO AT START
-
UP
Configurable up to +/
-
50
%
of max load capacity.
LOAD CELL POWER SUPPLY
5Vdc ± 5%, 120mA
(max 8 350
-
Ohm cells).
LOAD CELL CONNECTIONS
6 wires with Remote Sense.
DISPLAY DIVISIONS
10000e, 3 x 3000e f
or legal for trade weighing, expandable up to 800.000 for
internal use (with minimum signal coming from the 1,6 mV/V cell).
DISPLAYS
3590E:
- Red, high-luminosity LED indicators, with six digits (h 13 mm).
- Back lit graphic 160x32 dot LCD.
CPWE: Back lit graphic 160x32 dot LCD.
DATABASE/MEMORY
Database of 500 customers
(
3
descriptions of 20 characters).
Database of 500 products (2 descriptions of 20 characters).
Database of 500 vehicles (description of 20 characters, plate of 10 characters,
linked tare).
SIGNALS
3590E:
16 status LEDs. Graphic icons on LCD display.
CPWE: Graphic icons on LCD display.
CPWET: 3-way control light. Graphic icons on LCD display
KEYBOARD
I
mpermeable polycarbonate keyboard with 24 multifunction
(IP65 protection
degree), with membrane keys with audible and tactile feedback.
PARAMETER SETUP
Calibration and linearity (up to 8 points), fully digital and programmable from the
keyboard or from PC with Dinitools ™.
CLOCK/DATE
Fitted
, with buffer RAM.
SERIAL OUTPUTS
-
2 input/output RS232 ports on terminal board/ amp connector.
- 1 input/output RS485 port on terminal board or RS232 on amp connector.
- Management of PC keyboard or barcode reader
INPUTS AND OUTPUTS
3590EXP
,
3590EXT
and
CPWET
:
- 2 optoisolated inputs (optoisolated photo couplers), 12Vdc – 24Vdc, 20mA max
- 4 outputs (optoisolated photomosfets), 48Vac / 0.15A, 60Vdc / 0.15A, 10 Ω
max.
3590EXT (in IO version) and CPWE:
- 8 inputs (optoisolated photo couplers), 12Vdc – 24Vdc, 20mA max.
- 16 outputs (optoisolated photomosfets), 48Vac / 0.15A, 60Vdc / 0.15A.
