Dräger X-act 5000 User Manual

Dräger X-act 5000 5
Description
1.2 Definition of the alert icons in the text
The following alert icons are used in this document to provide and
highlight areas of the associated text that require a greater awareness
by the user. A definition of the meaning of each icon is as follows:
2 Description
2.1 Product overview
1 Tube socket (gas inlet)
2 Tube
3 Handle insert
4 Clamp for extension hose
5 LED windows (green or red)
6 Bar code reader with alert icon
7"UP" key
8"OK" key
9"DOWN" key
10 IR interface (for service by Dräger only)
11 Display
WARNING
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not
avoided, could result in physical injury, or damage to the
product or environment. It may also be used to alert against
unsafe practices.
NOTICE
Indicates additional information on how to use the instrument.
!
!
i
i
X-act 5000
00121900.eps
1
5
11
678910
2 3
4
CAUTION
INVISIBLE LASER AVOID
DIRECT EYE EXPOSURE
LASER CLASS 3R
