169
Child safety
DS5_en_Chap06_securite-enfants_ed02-2015
Installing child seats attached using
the seat belt
In accordance with European regulations, this table indicates the options for installing child seats secured using a seat belt and universally approved (a)
according to the weight of the child and the seating position in the vehicle:
Weight of the child and indicative age
Seat
Under 13 kg
(groups 0 (b) and 0+)
Up to approx 1 year
From 9 to 18 kg
(group 1)
1 to 3 years approx
From 15 to 25 kg
(group 2)
3 to 6 years approx
From 22 to 36 kg
(group 3)
6 to 10 years approx
Front passenger seat (c) with
height adjustment
U (R) U (R) U (R) U (R)
Outer rear seats (d) U U U U
Centre rear seat X X X X
(a) Universal child seat: child seat that can be installed in all vehicles using a seat belt.
(b) Group 0, from birth to 10 kg. Shells seats and baby carriers cannot be installed in the front
passenger seat.
When installed in the 2
nd
row, they prevent use of the other seats.
(c) Refer to the legislation in force in your country before installing your child on this seat.
(d) To install a child seat at the rear, rearward facing or forward facing, move the front seat
forwards, then straighten the backrest to allow sufficient space for the child seat and the child's
legs.
U: seat suitable for the installation of a child seat secured using a seat belt and universally
approved, rearward facing and/or forward facing.
U (R): same as U, with the passenger seat adjusted to the highest position and as far back as possible.
X: seat position not suitable for installation of a child seat for the weight class indicated.
Remove and stow the head restraint
before installing a child seat with a
backrest on a passenger seat. Refit the
head restraint once the child seat has
been removed.
