Front seats
Manual
1. Adjustments to the height and angle of
the head restraint
To raise it, pull upwards.
To lower it, press on the lug and the head
restraint at the same time.
2. Adjustment of the backrest angle
Turn the wheel to adjust the angle of the
backrest.
3. Adjustment of the seat height
Raise or lower the control lever the number
of times required to obtain the desired
position.
4. Forwards-backwards adjustment of
the seat position
Lift the control bar and slide the seat
forwards or backwards.
5. Adjustment of the driver's lumbar
support
Turn the wheel to obtain the desired level
of lumbar support.
Before moving the seat backwards, ensure that there is nothing that might prevent the full
travel of the seat, so as to avoid the risk of of jamming the seat caused by the presence of
objects on the floor behind the seat or rear passengers. If the seat jams, stop the movement
immediately.
