6.3 Display functions
Press the Enter (⮠) button to activate the menu options. Use the two middle buttons (⯅ and ⯆) to scrollthrough the
menu structure. Press the Enter (⮠) button to select an option. Press the (ESC) button to cancelor return to the previous
menu.
Menu map for display functions
Main menu Submenu Display information or Menu function
Measurements -
Load: [Total Load/Load (Primary)/Load (Group 1)/Load (Group 2)] : W, A, VA, pF
[Input/Output] : V, f
[Efficiency] : %
[Battery Info] : %, min, V, number of EBM, Age service, Age Warning
[Average power usage] : Total, Primary, Group 1, Group 2
[Cumulative power] : Total, Since Primary, Since Group 1, Since Group 2
Control
Load Segments
Group 1: ON / OFF
Group 2: ON / OFF
These commands overrule user settings for load segments.
Start battery test Starts a manual battery test (possible if load >10% and battery >80%)
Change battery Disable charger, Replace battery, Update settings
Connectivity test
Dry contacts test, Relay card test, Line failure test, Battery low test
Functions reset
Reset fault state, Reset power usage, Reset battery life, Card reset, Restore
factory settings
Settings
Local settings Sets product general parameters, see User settings
Input / output
settings
Sets input and output parameters
ON / OFF settings Sets ON / OFF conditions
Battery settings Sets battery configuration
Communication
settings
Sets communication parameters (input/output signals, remote signals, IPV4
address)
Event log
View Alarms
Displays the alarms stored
View Events Displays the events stored
View All Displays the faults and events stored
Reset All Clears the faults and events stored
Fault log
Fault list Displays the faults stored
Reset fault list Clears faults
Identification
Type / Model / Part Number / Serial Number / UPS Firmware / NMC Firmware /
IPV4 Address / IPV6 Address / Com card MAC Address
