Catalog Number
Default input
(Voltage/Current)
Input nominal voltages Input voltage window
5PX1000IRT2UG2 230V/10A
200-240V
160-294V
adjustable to 150~294
5PX1500IRT2UG2 230V/10A
5PX2200IRT2UG2 230V/16A
5PX2200IRT3UG2 230V/16A
5PX3000IRT2UG2 230V/16A
5PX3000IRT3UG2 230V/16A
10.5 Electrical input connections
Catalog Number Input connection Input cable
5PX1000IRT2UG2
IEC C14-10A Not provided
5PX1500IRT2UG2
5PX2200IRT2UG2
IEC C20-16A Schuko 16A to IEC320/16A
5PX2200IRT3UG2
5PX3000IRT2UG2
5PX3000IRT3UG2
10.6 Electrical output
All models Normal mode Battery mode
Voltage regulation
Boost : Vin*1.15
Buck : Vin*0.87
(-10% ,6%)
Efficiency >96%
1000-2200 > 82%
3000 > 85%
Frequency regulation +/-0.1 Hz
Nominal output
200/208/220/230/240V
Frequency Follows input frequency 50/60Hz
Output overload
[105%,120%] 30min
[120%,150%]5min
>150% 10S
[105% ~110%] 10s
[110%~150%]1s,
>150% 0.15s
