Frame parts and assembly
General directions
Coat the frame hardware with anti-seize compound
(Item20) before assembling. Connect the hardware
securely during assembly, then tighten firmly after securing
the frame on the mounting pad.
Frame height
The upper posts as assembled to the lower posts determine
the frame height. The range of frame-heights is shown in
Figures 1 and 2 and Table 1. The amount of required overlap
(upper post inside lower post) to obtain the desired frame
height is shown in Table 1.
Assembly and installation parts
Carefully unpack, separate, and identify the various parts.
See Table 2 for the KNOVA59-1 Substation Frame for NOVA
recloser, DAS switch, VCS-3 switch, and TVS sectionalizer.
See Table 3 for the KNOVA59-3 Substation Frame for NOVA
STS recloser.
Table 1. Frame Heights and Overlap
Frame Height
mm (inches)
Overlap
mm (inches)
2216 (87.25) 724 (28.5)
2292 (90.25) 648 (25.5)
2369 (93.25) 572 (22.5)
2445 (96.25) 495 (19.5)
2521 (99.25) 419 (16.5)
2597 (102.25) 343 (13.5)
2673 (105.25) 267 (10.5)
2750 (108.25) 191 (7.5)
2826 (111.25) 114 (4.5)
Table 2. KNOVA59-1 Substation Assembly and Installation Parts
Item Description Part Number Quantity
1 Support Angle VCS10011860001 5
2 Upper post, left 6A00378601 2
3 Upper post, right 6A00378602 2
4 Lower post, right RA01152001 2
5 Lower post, left RA01152002 2
6 Cross brace, short R001533002 4
7 Cross brace, long R001533008 4
8 Control mounting strap KM00001366X000 1
9 Hex-head cap screw, 1/2-13 X 1.25” 730115150125A 34
10 Hex-head cap screw, 1/2-13 X 1.50” 730115150150A 4
11 Hex-head cap screw, 1/2-13 X 1.75” 730115150175A 10
12 Hex-head cap screw, 1/2-13 X 2.5” 730115150250A 2
13 Hex nut, 1/2-13 880215113050A 50
14 Spring lockwasher, 1/2-med 900815050000A 50
15 Washer 900215050000A 2
16 Spacer KA20280061 12
17 Caplug bolt cover .5” KA20730057 2
18 Caplug retainer, .5” KA20730058 2
20 Anti-seize compound KA23640017 3
IMPORTANT
Determine the desired frame height and required overlap
before beginning. This will affect the assembly process for
the substation frame.
5
SUBSTATION FRAME KNOVA59-1 AND KNOVA59-3 ASSEMBLY AND INSTALLATION INSTRUCTIONS MN280043EN January 2016
