EATON Heavy-Duty Series 2 Hydrostatic Pumps Parts and Repair E-PUPI-TS004-E October 2004
This section provides the information necessary to troubleshoot a typical hydrostatic system using an Eaton
Series 2 hydrostatic pump. Using this section will help you to diagnose any minor problems that may occur.
Maintaining cleanliness while you work will prevent contamination of the hydrostatic system and insure contin-
uous and satisfactory transmission life.
Manual
Displacement
Control
CBA
Electronic Solenoid
Operated Control
With Electronic
Feedback
Swash
p
late Sensor
Proportional
Solenoids (2)
Troubleshooting
