Eaton SPD Series User Manual

Instruction Manual IM01005031E - rev.7
Effective December 2020
Eaton www.eaton.com 21
Eaton SPD Series for mounting external
to electrical distribution equipment
6.0 SPD display rotation
The SPD display can be rotated on the SPD enclosure, up to 360
degrees. This allows you to position the display for the best visibil-
ity regardless of the position in which the SPD is installed.
Rotations are at 90, 180, and 270 degrees. Reposition the SPD
display as follows:
1. Remove power from the unit.
2. Remove the two Phillips head screws that hold the display.
3. Rotate the display to the desired position. Be careful not to
overstress the display ribbon cable.
4. Place the display back onto the SPD enclosure. Again, be
careful not to overstress or crimp the ribbon cable.
5. Replace the two Phillips head screws. Tighten screws to
1.35 N∙m (12 in-lbs).
6. Restore power to the unit.
7.0 IEC approved models
Eaton’s one-port low-voltage surge protective device delta mod-
els SPD120480D3M, SPD160480D3M and SPD200480D3M
meet the requirements of IEC 61643-11 / EN 61643-11, Part 11:
Test Class II, and are intended to be installed in applications
with a degree of protection rated IP 20.
The delta models are intended for use with a 3 phase TN-S
system with PE and neutral distribution, 5 conductor with a
minimum 10 AWG or 6 mm
2
. The delta models are also intend-
ed for use with a 3 phase TN-C system with PEN distribution,
4 conductor with a minimum 10 AWG or 6 mm
2
. Screws used
for connection to ground shall be #10-32 x 3/8” and shall not be
zinc or aluminum. This product is not serviceable and contains
no replacement parts.
Additional product information and ratings for IEC applications:
•
The SPD contains internal disconnects with a short circuit
current rating I
SCCR
of 200kA.
•
Residual current IPE for this product is 5 mA.
•
Operating temperature is normal -5°C to 40°C (23°F to
104°F).
•
Humidity range is 5% through 95% non-condensing.
•
The SPD may be mounted directly to earthed conductive sur-
face, installed as per this manual.
•
Temporary overvoltage rating UT = 402.6V.
•
Withstand or safe failure mode, t
T
= 120 minutes, U
T
= 526V.
•
Modes of protection as marked on a delta SPD = L - L,
L -G(PE).
Table 3. Viewable events
Web UI viewable logs LCD viewable logs
Event type
General
log
last 500
events
Low
surge log
last 2000
events
Medium
surge log
last 1500
events
High
level
surge log
last 1000
events
Audit
power
log
Audit fw
update
log
Audit
user
log
All
events
last 40
events
Low
level
surges
last 20
events
Medium
level
surges
last 20
events
High
level
surges
last 20
events
Phase A protection reduced to % X X
Phase B protection reduced to % X X
Phase C protection reduced to % X X
N-G protection reduced to % X X
Phase A protection loss X X
Phase B protection loss X X
Phase C protection loss X X
N-G protection loss X X
Audible alarm silenced X X
Power off/ power loss X X
Power on/ power restored X X
Phase A low, medium or high surge X X X X X X X
Phase B low, medium or high surge X X X X X X X
Phase C low, medium or high surge X X X X X X X
Device restart X
Firmware update time stamp X
User login & logout X
