E18-DTU(Z27-ETH) User Manual
Copyright ©2012-2023
，Chengdu Ebyte Electronic Technology Co.,Ltd.
7
Chapter 2 Specification Parameters
2.1
Main specifications
project
illustrate
Operating voltage
8~28V DC, 12V or 24V power supply is recommended
interface
Network port (RJ45), 10Mbps
Working mode
TCP Server（default）、TCP Client、UDP Server、UDP Client、HTTP Client、
MQTT Client
Socket connection
The TCP server supports 6-way client connections
Network protocols
TCP/UDP
、
MQTT
、
HTTP
、
IPv4
、
DHCP
、
DNS
How to obtain an IP
Static IP (default)、DHCP
DNS domain name
resolution
Support
Domain name resolution
server
114.114.114.114（Customizable）
Configuration mode
Web page, parameter configuration tool, AT command
IP address
192.168.3.7（Customizable）
User name
admin
（
Customizable
）
password
admin（Customizable）
Local port
8887
（
Customizable
）
Subnet mask
255.255.255.0（Customizable）
gateway
192.168.3.1
（
Customizable
）
Serial port cache
1024 Byte
Packaging mechanism
512 Byte
Serial port baud rate
1200 ～ 230400 bps（Default 115200） Note: It is recommended to use the default
parameters, but it is not recommended to modify them
Data bits
5、6、 7、8（default） Note: It is recommended to use the default
parameters, but it is not recommended to modify them
Stop bit
1 （ default ） 、 2 Note: It is recommended to use the default
parameters, but it is not recommended to modify them
Check digit
None（default）、 Odd、Even Note: It is recommended to use the default
parameters, but it is not recommended to modify them
Flow control
Not supported
Product size
84×82×25mm
Product weight
118g ± 2g
Operating temperature
and humidity
-40 ～ +85℃、5% ～ 95%RH（No condensation）
Storage temperature and
humidity
-40 ～ +105℃、5% ～ 95%RH（No condensation）
