ECS H55H-I User Manual

32
Using BIOS
Advanced Chipset Setup
This page sets up more advanced information about your system. Handle this page
with caution. Any changes can affect the operation of your computer.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Advanced Chipset Setup
PAVP Mode Lite
Share Memory Size 64MB
DVMT Memory 256MB
Memory Remap Feature Enabled
HDMI Audio Enabled
Help Item
GMCH Protected Audio
Video Path (PAVP)
BIOS support.
PAVP Mode (Lite)
This item allows you to select the PAVP (Protected Audio-Video Path) mode.PAVP
supports secure playback of Intel HD Audio and Video content.
Share Memory Size (64MB)
This item lets you allocate a portion of the main memory for the onboard VGA
display application.
DVMT Memory (256MB)
When set to Fixed Mode, the graphics driver will reserve a fixed portion of the
system memory as graphics memory
, according to system and graphics requirements.
Press <Esc> to return to the main menu setting page.
Memory Remap Feature (Enabled)
This item allows you to remap the overlapped PCI memory above the total physical
memory if you have a 64 bit OS and 8 GB of RAM.
HDMI Audio (Enabled)
This item is used to enable or disable the NB HDMI audio support.

: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help

ECS H55H-I Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	-
Compatible processor series	Intel Core i3, Intel Core i5
S/PDIF out connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	6
Audio chip	Realtek ALC892
Power source type	ATX
Audio output channels	- channels
Motherboard form factor	mini ITX
On-board graphics card	No
Parallel processing technology support	Not supported
LAN controller	Realtek RTL8111D(L)
Networking features	Gigabit Ethernet
BIOS type	AMI
BIOS memory size	64 Mbit

Weight and Dimensions

Width	170 mm
