ECS H55H-I User Manual

40
Using BIOS
M.I.B. II (MB Intelligent BiosII)
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have in-
stalled in your system.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
M.I.B.II (MB Intelligent BIOS II)
Help Item
Intel (R) Core (TM) i5 CPU 661 @ 3.33GHz
Ratio Status: Unlocked (Min: 09, Max: 25)
Ratio Actual Value: 25
Current Memory Frequency : 1333MHz
Memory Current Type: 9-24-9-9-10-74-5-4-5-20
CPU Vcore : 1.164 V
VDIMM : 1.500 V
VAXG : 1.368 V
Performance Level Standard
DRAM Frequency Auto
Configure DRAM Timing by SPD Auto
Memory Hole Disabled
DRAM Command Rate Auto
CPU Over-clocking Func: Disabled
PCIE Over-clocking Func: Disabled
Spread Spectrum Enabled
Auto Detect DIMM/PCI Clk Enabled
Voltage Function Disabled
: Move F10: Save ESC: Exit
+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help

Standard
Enhanced
Options
DRAM Command Rate (Auto)
This item specifies the rate of the DRAM Command.
CPU Over-clocking Func (Disabled)
This item decides the CPU over-clocking function installed in your system. If the
over-clocking fails, please turn off the system power. And then, hold the PageUp key
(similar to the Clear CMOS function) and turn on the power, the BIOS will recover
the safe default.
DRAM Frequency (Auto)
This item enables users to adjust the DRAM frequency. The default setting is auto and
we recommend users leave the setting unchanged. Modify it at will may cause the
system to be unstable.
Configure DRAM Timing by SPD (Auto)
When this item is set to enable, the DDR timing is configured using SPD. SPD (Serial
Presence Detect) is located on the memory modules, BIOS reads information coded
in SPD during system boot up.
Memory Hole (Disabled)
This item allows users to enable or disable memory hole remapping.
Performance Level (Standard)
This item shows the performance level of the components, the options are: Standard
and Enhanced.

ECS H55H-I Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	-
Compatible processor series	Intel Core i3, Intel Core i5
S/PDIF out connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	6
Audio chip	Realtek ALC892
Power source type	ATX
Audio output channels	- channels
Motherboard form factor	mini ITX
On-board graphics card	No
Parallel processing technology support	Not supported
LAN controller	Realtek RTL8111D(L)
Networking features	Gigabit Ethernet
BIOS type	AMI
BIOS memory size	64 Mbit

Weight and Dimensions

Width	170 mm
