ECS H55H-I User Manual

36
Using BIOS
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Help Item
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
PC Health Status


: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
Case Open Warning Disabled
Chassis Opened No
Smart Fan Function (Press Enter)

Scroll to this item and press <Enter> to view the following screen:
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Smart Fan Function
Help Item
Disabled
Enabled
Options

: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
CPU SMART FAN Control Enabled
SMART Fan Mode Normal
CPU SMART Fan start PWM 56
CPU SMART Fan start TEMP (°C)32
DeltaT +3
SMART Fan Slope PWM value 4 PWM value/°C
CPU FAN Full Limit Temp 81°C
CPU SMART FAN Control (Enabled)
This item allows you to enable/disable the control of the CPU fan speed by changing
the fan voltage.
-=- System Hardware Monitor-=-
Smart Fan Function Press Enter
CPU Temperature : 38°C/100°F
System Temperature : 34°C/93°F
CPU Fan Speed : 978 RPM
CPU Vcore : 1.164 V
VDIMM : 1.524 V
VAXG : 1.368 V

ECS H55H-I Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	-
Compatible processor series	Intel Core i3, Intel Core i5
S/PDIF out connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	6
Audio chip	Realtek ALC892
Power source type	ATX
Audio output channels	- channels
Motherboard form factor	mini ITX
On-board graphics card	No
Parallel processing technology support	Not supported
LAN controller	Realtek RTL8111D(L)
Networking features	Gigabit Ethernet
BIOS type	AMI
BIOS memory size	64 Mbit

Weight and Dimensions

Width	170 mm
