ECS H55H-I User Manual

35
Using BIOS
Press <Esc> to return to the main menu setting page.
Init Display First (PCI)
Use this item to select which graphics controller to use as the primary boot devices.
PCI/PnP Setup
This page sets up some parameters for devices installed on the PCI bus and those
utilizing the system plug and play capability.
Help Item
Init Display First PCI
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
PCI/PnP Setup
Select which graphics
controller to use as
the primary boot
device.

: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
Press <Esc> to return to the main menu setting page.
ACPI T State (Enabled)
Report processor throttling in ACPI
C1 Auto Demotion (Enabled)
When enable, CPU will conditionally demote C3/C6/C7 requests to C1 based on
uncore auto-demote information.
C3 Auto Demotion (Enabled)
When enable, CPU will conditionally demote C6/C7 requests to C3 based on uncore
auto-demote information.
EUP Support (Enabled)
When enabled, system can not resume by some devices (PCI/PCIE/PME/Ring/RTC,etc)
at S5 state. You can use this item to save power.

ECS H55H-I Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	-
Compatible processor series	Intel Core i3, Intel Core i5
S/PDIF out connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	6
Audio chip	Realtek ALC892
Power source type	ATX
Audio output channels	- channels
Motherboard form factor	mini ITX
On-board graphics card	No
Parallel processing technology support	Not supported
LAN controller	Realtek RTL8111D(L)
Networking features	Gigabit Ethernet
BIOS type	AMI
BIOS memory size	64 Mbit

Weight and Dimensions

Width	170 mm
