ECS LIVA Z User Manual

2
LIVA Z MINI PC USER MANUAL
Chapter 1
Rear Panel I/O
CPU/Chipset
• Support DDR3L up to 8GB
- Dual-channel DDR3L SDRAM SO-DIMM
Memory
• 2 x M.2 slots
(One supports Wireless card, the other
supports 2242 SSD card)
• Support eMMC 32/64, 1 x M.2 2242 SSD
Expansion
Storage
• Intel Apollo lake Mobile SoC
Specificaons
Note:
ID design and specificaon may vary, please refer
to actual goods you purchase.
Slots
• Support IEEE 802.11 b/g/n/ac and
Bluetooth 4.0
Wireless
• 1 x DC_IN port (19V only)
• 2 x Giga LAN connectors
• 1 x HDMI port
• 1 x Mini Display port
®

ECS LIVA Z Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Maximum internal memory	8 GB
Storage media	eMMC
Optical drive type	No
Total storage capacity	64 GB
Ethernet LAN	Yes
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 500
HDMI version	1.4
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Chassis type	-
Product color	Black
Placement supported	Horizontal
Operating system architecture	64-bit
Product type	Mini PC
Processor cache	2 MB
Processor model	N3350
Processor family	Intel® Celeron® N
Processor frequency	1.1 GHz
Power supply input voltage	100 - 240 V
Intel Identity Protection Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00

Weight and Dimensions

Depth	128 mm
Width	117 mm
Height	33 mm
Weight	- g
