ECS LIVA Z User Manual

LIVA Z MINI PC USER MANUAL
23
Chapter 2
:Select Screen
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
+/- : Change Opt.
Enter : Select


:Select Item
Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc.
SATA Configuration
This page provides the information and configuration for SATA
storages.

SATA Configuration
SATA Mode [AHCI]
SATA Port Not Present
M.2 SSD SATA SSD (64.0GB)
Determines how SATA
controller(s) operate.
SATA Mode (AHCI Mode)
Use this item to select SATA mode.
Aptio Setup Utility - Copyright (C) 2016 American Megatrends, Inc.
Advanced
SATA Port (Not Present)
This item displays the information of SATA storage installed on the
SATA port.
Press <Esc> to return to the Advanced Menu page.
M.2 SSD (SATA SSD (64.0GB))
This item displays the information of M.2 SATA SSD installed on the
M.2 socket.

ECS LIVA Z Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Maximum internal memory	8 GB
Storage media	eMMC
Optical drive type	No
Total storage capacity	64 GB
Ethernet LAN	Yes
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 500
HDMI version	1.4
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Chassis type	-
Product color	Black
Placement supported	Horizontal
Operating system architecture	64-bit
Product type	Mini PC
Processor cache	2 MB
Processor model	N3350
Processor family	Intel® Celeron® N
Processor frequency	1.1 GHz
Power supply input voltage	100 - 240 V
Intel Identity Protection Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00

Weight and Dimensions

Depth	128 mm
Width	117 mm
Height	33 mm
Weight	- g
