LIVA Z MINI PC USER MANUAL
51
Chapter 3
Installing the Windows OS
There are two ways to install the Windows OS:
1. Install Windows OS via Windows official DVD.
2. Install Windows OS via USB flash drive.
a) Create an ISO file from the Windows 8.1 DVD.
b) Download the Windows 7 USB/DVD Download Tool from
Microsoft and install it. Please refer to the link:
This free program from Microsoft properly formats your flash drive
and then copies the contents of the Windows 8.1 installation ISO
file to the flash drive.
h t tp://ww w.microsoftst ore.com/s t ore/msusa/html/
pbPage.Help_Win7_usbdvd_dwnTool.
c) Boot from the USB device that you just created to start the
Windows 8.1 installing process.
You need to change the booting priority in BIOS in order to
boot from USB device. Enter into BIOS and select the Boot
in menu (or press the hotkey F7), set USB drive as the first
booting priority.
Chapter 3
Using the Motherboard Software

ECS LIVA Z Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Maximum internal memory	8 GB
Storage media	eMMC
Optical drive type	No
Total storage capacity	64 GB
Ethernet LAN	Yes
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 500
HDMI version	1.4
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Chassis type	-
Product color	Black
Placement supported	Horizontal
Operating system architecture	64-bit
Product type	Mini PC
Processor cache	2 MB
Processor model	N3350
Processor family	Intel® Celeron® N
Processor frequency	1.1 GHz
Power supply input voltage	100 - 240 V
Intel Identity Protection Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00

Weight and Dimensions

Depth	128 mm
Width	117 mm
Height	33 mm
Weight	- g
