LIVA Z MINI PC USER MANUAL

vii

TABLE OF CONTENTS

Introducing the PC 1

Introduction....................................................1

Specifications..................................................2

Front and Rear I/O............................................4

Motherboard Components..............................6

Header Pin Definition ....................................9

Chapter 1 1

Chapter 2 11

Using BIOS 11

About the Setup Utility...................................11

The Standard Configuration....................12

Entering the Setup Utility.........................12

Resetting the Default CMOS Value..........13

Using BIOS.....................................................14

BIOS Navigation Keys..............................15

Main Menu............................................16

Advanced Menu......................................17

Chipset Menu..........................................39

M.I.B III(MB Intelligent BIOS III) Menu.....42

Boot Menu.............................................44

Security Menu........................................46

Preface

Questions and Answers:

Need help?

Do you have a question about the ECS LIVA Z and is the answer not in the manual?

ECS LIVA Z Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Maximum internal memory	8 GB
Storage media	eMMC
Optical drive type	No
Total storage capacity	64 GB
Ethernet LAN	Yes
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 500
HDMI version	1.4
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Chassis type	-
Product color	Black
Placement supported	Horizontal
Operating system architecture	64-bit
Product type	Mini PC
Processor cache	2 MB
Processor model	N3350
Processor family	Intel® Celeron® N
Processor frequency	1.1 GHz
Power supply input voltage	100 - 240 V
Intel Identity Protection Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00
