ECS LIVA Z User Manual

LIVA Z MINI PC USER MANUAL
19
Chapter 2
:Select Screen
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
+/- : Change Opt.
Enter : Select


:Select Item
Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2016 American Megatrends, Inc.
Power Management Setup
Resume By PME [Disabled]
Resume By USB [Disabled]
Resume By RTC Alarm [Disabled]
EuP Function [Enabled]
Enable/Disable
functionality: Resume
by PCI/PCIE devices,
Onboard LAN
controllers, Ring
Resume By PME (Disabled)
This item specify whether the system will be awakened from power
saving modes when activity or input signal of the specified
hardware peripheral or components is detected.
Resume By USB (Disabled)
This item allows you to enable/disable the USB device wakeup
function from S3 mode.

Power Management Setup
This page sets up some parameters for system power management
operation.
Advanced

ECS LIVA Z Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Maximum internal memory	8 GB
Storage media	eMMC
Optical drive type	No
Total storage capacity	64 GB
Ethernet LAN	Yes
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 500
HDMI version	1.4
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Chassis type	-
Product color	Black
Placement supported	Horizontal
Operating system architecture	64-bit
Product type	Mini PC
Processor cache	2 MB
Processor model	N3350
Processor family	Intel® Celeron® N
Processor frequency	1.1 GHz
Power supply input voltage	100 - 240 V
Intel Identity Protection Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00

Weight and Dimensions

Depth	128 mm
Width	117 mm
Height	33 mm
Weight	- g
