Acclarix AX3 Series Diagnostic Ultrasound System User Manual Exam Data Management
- 98 -
Delete the selected image.
Export selected images to a removable media currently available. Plug in a
USB disk, select an image, press this button and the following confirmation
dialog pop-up:
Select the export path from destination drop list menu, select the export
format and click OK to export.
If there is no USB plugged in, the Export button is unavailable.
Note:
Cine clips are not supported to export in AVI and DICOM format for this
release.
Load the raw data of the selected image or clip for post-processing. On the
touch screen, press the mode tabs, for example "B Mode", to adjust the
imaging parameters for post-processing images.
Note: The Dual image/clip can not be loaded to review in this release.
Table 9-1 Review Touch Screen Controls
