Acclarix AX3 Series Diagnostic Ultrasound System User Manual Measurements and Reports
- 78 -
No.
Abdomen Measurement
Description
Tool
2.14
IMV
Inferior Mesenteric Vein
Table 8-1 Abdomen Measurement
* The tools can be switched by Tool Options in the touch screen after the Measurement is selected.
8.2.2. Gynecology Measurements
Gynecology measurements include uterus and ovary.
No.
Gynecology Measurement
Description
Tool
Section 1: B-mode Measurements
1.1
Uterus
Uterus L
Uterus Length
Caliper
Uterus W
Uterus Width
Uterus H
Uterus Height
Endo
Endometrium Thickness
UT-Cavity
Uterine Cavity Depth
1.2
Cervix
Cervix L
Cervix Length
Cervix W
Cervix Width
Cervix H
Cervix Height
1.3
Ovary
Ovary L
Ovary Length
Ovary W
Ovary Width
Ovary H
Ovary Height
1.4
Cyst**
Cyst D1
Cyst Distance 1
Cyst D2
Cyst Distance 2
Cyst D3
Cyst Distance 3
1.5
Follicle**
Fol. D1
Follicle Distance 1
Fol. D2
Follicle Distance 2
Fol. D3
Follicle Distance 3
1.6
Fluid POD
Fluid Pouch of Douglas
Section 2: Doppler Measurements
2.1
Ovary A
Ovary Artery
Caliper*
Trace*
Auto Trace*
2.2
Ut. A
Uterine Artery
Table 8-2 Gynecology Measurements
*The tools can be switched by Tool Options in the touch screen after the Measurement is selected.
** The measurement method including 1 Distance, 2 Distances and 3 Distances can be configured in
Measure Preset. See Section 10.3.5 for details.
