Electrolux DF36 Service Manual

2
This document cannot be reproduced or passed to third parties without authorization of Electrolux do Brasil S.A.
CONTENTS
1. TOOLS AND EQUIPMENT REQUIRED FOR THE PRODUCT MAINTENANCE......................................... 3
2. DISASSEMBLING OF THE FREEZER...................................................................................................... 3
2.1 Access to the Freezer Components .................................................................................................... 3
2.2 Access to the Refrigerator Components .............................................................................................. 4
2.3 Removal of the Top Flow Assemblage ................................................................................................. 5
2.4 Removal of the Air Duct and Gutter ..................................................................................................... 5
2.5 Removal of the Thermostat .................................................................................................................. 6
2.6 Disassembling of the Door Handle....................................................................................................... 8
2.7 Removal of the Doors .......................................................................................................................... 8
2.8 Replacement of the Motofan ................................................................................................................ 9
2.9 Disassembling of the Evaporator ......................................................................................................... 10
2.10 Removal of the Timer ......................................................................................................................... 12

Electrolux DF36 Specifications

General

Brand	Electrolux
Model	DF36
Category	Refrigerator
Language	English
