3
This document cannot be reproduced or passed to third parties without authorization of Electrolux do Brasil S.A.
1. TOOLS AND EQUIPMENT REQUIRED FOR THE PRODUCT MAINTENANCE
2.1.2 With a Phillips screwdriver, remove the top flow
screws.
2.1.3 Remove the top flow assemblage by pulling it
from the top.
• Digital multimeter plier (Minipa ET 3200 A)
• Curved-noose plier
• Pipe-cutting plier (LRSZ –VULCAN))
• Cutting plier
• Lokring plier (VULCAN)
• Lockring joints 8 to 6, aluminum - copper
• Screwdriver 1/4 x 6”
• Phillips screwdriver 3/16 x 6"
• Torx tools set
• Digital Multimeter
• Thermal-hygrometer (SUNDO)
• Digital Thermometer with 4 sensors (Full Gauge)
• Lokprep sealant
2. PRODUCT DISASSEMBLING
2.1 Access to the Freezer Components
2.1.1 Remove all the freezer accessories.
2.1.4 With a Phillips screwdriver, remove the two
screws so as to loose the cover.
