Emerson Copeland EVM Series User Manual

15
Ground Wiring
Warning!
Connect only in voltage-free state!
Input power and motor cable stripping lengths
Table 3. Stripping Lengths
Power Wiring in Inches (mm) Motor Wiring in Inches (mm)
Size
A1 B1 C1
D1
A2 B2 C2
D2
FR1
0.39
2.76
0.3
2.76
0.39
2.76
0.39
2.76
(10)
(70)
(10) (70)
(10) (70)
(10) (70)
FR2
0.47
2.76
0.4
2.76
0.47
2.76
0.47
2.76
(12)
(70)
(12) (70)
(12) (70)
(12) (70)
FR3
0.47
3.54
0.4
3.54
0.47
3.54
0.47
3.54
(12)
(90)
(12) (90)
(12) (90)
(12) (90)
FR4
0.79
4.53
0.7
4.53
0.79
4.53
0.79
4.53
(20)
(115) (20)
(115) (20)
(115) (20)
(115)
